GENERAL PRODUCT SPECIFICATION(Continued)
8639 000 15121
2003-12-19
590
13
31
C.C.Liao
Go to cover page
202P Gs3 CM25
DELL P1230 M25P
57
22" CMTR-M25P-Dell-P1230
TYPE : 6L3P10/76
OEM : Dell 130KHz
MODENO.25262728
RESOLUTION 1600 x 1000 1792 x 1344 1920 x 1440 1856 x 1392
Dot clock(MHz) 1 94.208 204.750 297.594 218.250
f h 89.250 kHz 83.640 kHz 112.725kHz 86.333 kHz
A ( us ) 11.204 11.956 8.871 11.583
B ( us ) 0.906 0.977 0.699 1.026
C ( us ) 1.483 1.602 1.210 1.613
D ( us ) 8.239 8.752 6.452 8.504
E ( us ) 0.577 0.625 0.511 0.440
f v 85.000 Hz 60.000 Hz 75.000 Hz 59.995 Hz
O (ms ) 11.765 16.667 13.333 16.668
P ( ms ) 0.034 0.036 0.0266 0.035
Q (ms ) 0.515 0.550 0.5234 0.498
R ( ms ) 11.204 16.069 12.774 16.124
S ( ms ) 0.011 0.012 0.0089 0.012
SYNC. H/V - / + - / + -/+ -/+
POLARITY
SEP . SYNC Y Y Y Y
MODENO.29303132
RESOLUTION 1920 x 1200 1920 x 1440 1920 x 1440 2048 x 1536
CVT
Dot clock(MHz) 246.590 234.000 320.207 339.000
f h 93.975 kHz 90.000 kHz 120.560 kHz 120.384 kHz
A ( us ) 10.641 11.111 8.295 8.307
B ( us ) 0.844 0.889 0.675 0.661
C ( us ) 1.427 1.470 1.149 1.133
D ( us ) 7.786 8.205 5.996 6.041
E ( us ) 0.584 0.547 0.475 0.472
f v 75.000 Hz 60.000 Hz 80.000 Hz 74.959 Hz
O (ms ) 13.333 16.667 12.500 13.341
P ( ms ) 0.032 0.033 0.025 0.033
Q (ms ) 0.521 0.622 0.523 0.523
R ( ms ) 12.769 16.000 11.944 12.759
S ( ms ) 0.011 0.011 0.008 0.025
SYNC.H/V -/+ -/+ +/+ -/+
POLARITY
SEP.SYNCYYYY
