16 Video Cassette Playback
•
If the tape you want to play is
already in the DVD/VCR, make sure
the DVD/VCR power is on and the
DVD/VCR is in VCR mode and VCR
position. (The green VIDEO light and
the VCR/TV light will appear on the
front of the DVD/VCR.) Press VCR,
then press PLAY B (K).
• Other tape playback options and
features are on pages 39-46.
• When you play a tape recorded in
S-VHS format on this unit, you can
not get the high resolution that
would be available on an S-VHS
VCR. Noise lines (black and white
streaks) may appear on the picture.
• If REPEAT PLAY is ON, playback will
begin automatically when you insert
a tape, even when the record tab is
intact. Details are on page 39.
• You must connect the DVD/VCR to
a TV using the RF coaxial cable or
the audio/video cables in order to
use the VCR features.
Helpful Hints
Read and follow the steps below to play a tape.
1
Turn on the TV and set it to channel 3 or 4,
whichever channel the CH3/CH4 switch on the back of the
DVD/VCR is set to. Or, if you connected the DVD/VCR to
the TV using audio and video cables, select the correct
audio and video in channel at the TV. Details are on page 11.
2
With the DVD/VCR power off, insert a tape in the
cassette compartment of the DVD/VCR. The Power,
VIDEO, VCR/TV, and CST. IN lights will appear on the
front of the DVD/VCR. If the tape’s record tab has been
removed, playback will start automatically.
If the DVD/VCR power is already on, press OUTPUT
SELECT to put the DVD/VCR in VCR mode if necessary.
The green VIDEO light will appear on the front of the
DVD/VCR.
3
If playback does not start automatically, press VCR,
then press PLAY B (o).
4
Press STOP C (p) to stop playback.
5
Press REW h (s) to rewind the tape.
6
After the tape stops, press STOP/EJECT on the
DVD/VCR to remove the tape.
1
2
4
5
3
6
Press STOP/EJECT on the
DVD/VCR.
Turn on the TV.
Insert a tape in the
DVD/VCR.
VCR
