Philips DVD755VR - Page 140

Spare Parts Lists
EN 25DVD755VR 2.
R716 4822 051 20102 1k 5% 0,1W
R717 4822 117 11373 100Ω 1% RC12H 0805
R718 4822 117 11373 100Ω 1% RC12H 0805
R719 4822 117 13577 330Ω 1% RC12H 0805
1,25W
R7S1 4822 051 20223 22k 5% 0,1W
R801 4822 051 20335 3M3 5% 0,1W
R802 4822 051 20333 33k 5% 0,1W
R803 4822 117 12955 2k7 1% 0,1W 0805
R804 4822 051 20393 39k 5% 0,1W
R805 4822 117 12955 2k7 1% 0,1W 0805
R806 4822 051 20333 33k 5% 0,1W
R807 4822 051 20471 470Ω 5% 0,1W
R808 4822 117 10833 10k 1% 0,1W
R809 4822 117 10965 18k 1% 0,1W
R810 4822 117 11373 100Ω 1% RC12H 0805
R811 4822 117 11373 100Ω 1% RC12H 0805
R812 4822 051 20102 1k 5% 0,1W
R821 4822 117 11449 2k2 5% 0,1W 0805
R822 4822 117 10837 100k 1% 0.1W
R823 4822 117 11449 2k2 5% 0,1W 0805
R824 4822 117 10837 100k 1% 0.1W
R825 4822 051 20561 560Ω 5% 0,1W
R826 4822 051 20561 560Ω 5% 0,1W
R835 4822 117 11927 75Ω 1% 0,1W
R841 4822 117 13577 330Ω 1% RC12H 0805
1,25W
R842 4822 117 13577 330Ω 1% RC12H 0805
1,25W
R850 4822 117 11373 100Ω 1% RC12H 0805
R851 4822 117 11373 100Ω 1% RC12H 0805
R861 4822 051 20472 4k7 5% 0,1W
R862 4822 051 20472 4k7 5% 0,1W
R863 4822 051 20472 4k7 5% 0,1W
R864 4822 051 20472 4k7 5% 0,1W
R874 4822 117 11927 75Ω 1% 0,1W
R875 4822 051 20472 4k7 5% 0,1W
R876 4822 051 20472 4k7 5% 0,1W
R890 4822 117 11927 75Ω 1% 0,1W
R901 4822 117 11383 12k 1% 0,1W
R902 4822 117 10833 10k 1% 0,1W
R903 4822 117 11927 75Ω 1% 0,1W
R904 4822 051 20561 560Ω 5% 0,1W
R905 4822 051 20561 560Ω 5% 0,1W
R906 4822 051 20561 560Ω 5% 0,1W
R907 4822 051 20561 560Ω 5% 0,1W
R908 4822 051 20008 0Ω jumper . (0805)
R909 4822 051 20008 0Ω jumper . (0805)
R910 4822 051 20008 0Ω jumper . (0805)
R911 4822 051 20102 1k 5% 0,1W
R913 4822 117 11927 75Ω 1% 0,1W
R914 4822 117 11927 75Ω 1% 0,1W
R919 4822 051 20472 4k7 5% 0,1W
R920 4822 117 10361 680Ω 1% 0,1W
R927 4822 051 20102 1k 5% 0,1W
R928 4822 051 20008 0Ω jumper . (0805)
R929 4822 051 20008 0Ω jumper . (0805)
R930 4822 051 20102 1k 5% 0,1W
R931 4822 117 11503 220Ω 1% 0.1W
R932 4822 117 11503 220Ω 1% 0.1W
R933 4822 117 10837 100k 1% 0.1W
R934 4822 117 10837 100k 1% 0.1W
W714 9965 000 18656 1.0M K 2.3X3.4 L5 TP
W901 9965 000 18656 1.0M K 2.3X3.4 L5 TP
W902 9965 000 18656 1.0M K 2.3X3.4 L5 TP
W903 9965 000 18656 1.0M K 2.3X3.4 L5 TP
X301 9965 000 18657 HC49U BUBANG 4-
433709MHz 15P
X501 9965 000 18658 HC-49S BUBANG 10MHz +/-
30 PPM
X502 9965 000 18659 C-001R SEIKO EPSON
32.768 KHZ
X751 9965 000 18660 49U BUBANG 18432000HZ
30PPM 16

CS501 9965 000 18625 MPU11810MLB0 MIC DC 5V
1MA D-3
ES501 9965 000 18626 END (DI)
ES502 9965 000 18626 END (DI)
FL301 9965 000 18628 BIAC OSC,1CHIP 5V(KS-
75M) KWAN
IC201 9965 000 18629 LA70100M SANYO 30 SOP
ST SECAM
IC301 9965 000 18630 LA71750EM SANYO 100PIN
QFP TRA
IC501 9965 000 18631 HD6432197SA26F HITACHI
112PIN
IC503 9965 000 18632 CAT24W16P 8P DIP ST 16K
SERIAL
IC504 9965 000 18633 KIA7031P 3P 3.1V
RESET(TAPING)
IC505 9965 000 18634 KIA7042P
IC751 9965 000 14760 AUD UP MSP3417G-QG-B8-
V3
IC801 9352 631 46557 IC SM TDA9605H/N2
IC802 9965 000 18635 MM1443XJ SSOP-34 TP
CANAL S/W

LD501 9965 000 18649 LED(DI-CKD)LOCAL
MS501 9965 000 18650 NON 5V 1MA VERTICAL -G

RS501 9965 000 18653 SG-260 KODENSHI D33
REEL SENSO
RS502 9965 000 18653 SG-260 KODENSHI D33
REEL SENSO
SC901 9965 000 18654 DSAM-0121 DOOWON 2F-
21P(BL-BK)

TU701 9965 000 18655 TADC-S401D(SECAM,LGIT)
LG INOT
PSU PWB DVD755VR /xx
Various
A48 9965 000 18661 2003 POWER
X360,FLD,MTK
BD01 9965 000 18585 BEAD CORE
BFS3550R2FD8,R T/P

C101 9965 000 18666 435D SUNIL ELECTRONICS
0.1µF /2
C102 9965 000 18666 435D SUNIL ELECTRONICS
0.1µF /2
C103 9965 000 18667 100mF /400V SHL SMPS S/
Y
C104 9965 000 18668 0.022µF S 50V J PE TP
C105 9965 000 18669 0.01µF D 630V K PE NI TP
C106 9965 000 18670 HIGH-VOL 100P/1KV SMPS
SAMHWA
C109 9965 000 18671 10M SMS 50V M FM5 TP(5)
C110 9965 000 18672 1nF 400V M E(Z5U) R
C111 9965 000 18673 2200 pF 400V M E R
(NK,AD,SD)
C112 9965 000 18674 0.022µF 50V Z F TA26 S
C117 9965 000 18675 330µF KMG 50V M FM5
BULK
C121 4822 124 40196 220µF 20% 16V
C123 9965 000 18676 470µF KME TYPE 25V M
FM5 BULK
C126 9965 000 18677 220µF SMS,SG 25V 20%
FM5 TP 5
C127 4822 124 40201 1000µF 20% 16V
C128 4822 124 40849 330µF 20% 16V
C129 4822 124 40723 2200µF 20% 16V
C130 4822 124 41751 47µF 20% 50V
C131 4822 124 40184 1000µF 20% 10V
C132 4822 124 41751 47µF 20% 50V
C133 9965 000 18678 0.1µF S 50V J PE TP
C135 9965 000 18679 470P 50V K B TA26
C151 4822 124 40769 4,7µF 20% 100V
C152 4822 124 40769 4,7µF 20% 100V
C153 4822 124 11947 10µF 20% 16V
C154 9965 000 18557 100µF SRA 16V M FM5
TP(5)
C155 4822 124 11947 10µF 20% 16V
C156 4822 124 40769 4,7µF 20% 100V
C161 9965 000 18680 47M SRE 16V M FM5 TP(5)
C163 9965 000 18681 HIGH-VOL 220pF /1KV
CERAMIC

D101 9965 000 18682 ERA22-10 KFLB,TP ,R T/
P,FUJI
D102 9965 000 18683 EU01W(R-FORM) TP
SANKEN
D103 4822 130 32778 1SS133
D106 9965 000 18683 EU01W(R-FORM) TP
SANKEN
D107 9965 000 18565 RL104F TP RECTRON NON
400V 1A
D108 9965 000 18683 EU01W(R-FORM) TP
SANKEN
D110 9965 000 18684 HER302 BK RECTRON
DO201AD 100V
D111 9965 000 18685 1N5822 BK RECTRON
DO201AD 40V
D113 9965 000 18565 RL104F TP RECTRON NON
400V 1A
D114 9965 000 18686 RL104 R. TP GULF
SEMICONDUCTOR
D115 9965 000 18686 RL104 R. TP GULF
SEMICONDUCTOR
D117 9965 000 18686 RL104 R. TP GULF
SEMICONDUCTOR
D118 9965 000 18687 B10A45V1 BK KEC TO220
45V 10A
D121 4822 130 32778 1SS133
F101 4822 070 31602 21801.6(1.6A)
F102 4822 209 63611 ICP-N20X

L102 9965 000 19211 LFSQ2215V4-04220B
SAMWAH TECOM
L122 9965 000 19212 CHOCK(22mH ) 5MM TOKO
TP
L123 9965 000 19212 CHOCK(22mH ) 5MM TOKO
TP
L125 9965 000 19213 CHOCK ,20µH
KWANGSUNG LEAD CU

Q150 9965 000 07007 KSB1151-Y BK
Q153 9965 000 19214 SRA2203 TP AUK TO92
22K,22K
Q154 9965 000 19224 2SC5343-L TP AUK TO92
Q155 4822 130 63857 KTD1414
Q156 4822 130 41306 2SC1815GR
Q161 9965 000 19225 KTA1268-BL TP KEC
Q162 9965 000 19224 2SC5343-L TP AUK TO92

R100 9965 000 19226 1.5M Ω 1/2 W 5.00% MF10
R101 9965 000 19227 2.7/2W CEMENT SMPS V
R104 9965 000 19228 56k Ω 2 W 5.00% TR
R105 4822 116 52195 47Ω 5% 0,5W
R106 4822 116 52252 180k 5% 0,5W
R107 4822 116 52252 180k 5% 0,5W
R110 4822 116 52283 4k7 5% 0,5W
R111 4822 116 52234 100k 5% 0,5W
R112 9965 000 19229 220 Ω 1/6 W 5% TA26
R113 4822 116 52276 3k9 5% 0,5W
R114 9965 000 19230 1k Ω 1/6 W 5% TA26
R115 4822 116 52269 3k3 5% 0,5W
R116 4822 116 52263 2k7 5% 0,5W
R117 9965 000 19231 270 Ω 1/6 W 5% TA26
R118 4822 116 52234 100k 5% 0,5W
R119 4822 116 52234 100k 5% 0,5W
R124 9965 000 19232 0.35 Ω 2 W 5.00% TR
R125 4822 116 52283 4k7 5% 0,5W
R126 4822 116 52228 680Ω 5% 0,5W
R130 4822 116 52234 100k 5% 0,5W
R131 4822 116 52257 22k 5% 0,5W
R151 4822 116 52289 5k6 5% 0,5W
R152 4822 116 52289 5k6 5% 0,5W
R153 4822 116 52283 4k7 5% 0,5W
R154 9965 000 19230 1k Ω 1/6 W 5% TA26
R155 4822 116 52251 18k 5% 0,5W
R156 9965 000 19233 10k Ω 1/6 W 5% TA26
R157 9965 000 19230 1k Ω 1/6 W 5% TA26
R158 9965 000 18652 330 Ω 1/6 W 5% TA26
R159 9965 000 18652 330 Ω 1/6 W 5% TA26
R164 4822 116 52283 4k7 5% 0,5W
R167 4822 116 52186 22Ω 5% 0,5W
R168 4822 116 52186 22Ω 5% 0,5W
R170 9965 000 19233 10k Ω 1/6 W 5% TA26
R171 4822 116 52283 4k7 5% 0,5W
R172 4822 116 52283 4k7 5% 0,5W

T101 9965 000 19234 EER3534, 580UH SAMWHA/
FEELUX C
V101 9965 000 19235 SVC681D-10A SAMHWA
4.O CUT
BD101 9965 000 18662 S1WBA60(1A 600V)
SHIDENKEN
IC101 9965 000 18688 STR-G6351L SANKEN 5PIN
TO220 S
