Philips DVD755VR - Page 141

Spare Parts Lists
EN 26 DVD755VR2.
IC102 9965 000 18689 LTV-817B,PHOTO
COUPLER(LITEON)
IC103 4822 209 12767 KIA431
IC151 9965 000 19209 KIA78R08PI CU KEC 4P TO-
220IS
IC152 9965 000 19210 KIA278R33PI-CU KEC 4PIN
TO-220
ZD101 9965 000 19243 UZ-3.3BSB 26MM TP
PYUNG CHANG
ZD103 4822 130 82665 MTZ13A
ZD104 9965 000 19244 UZ-30BSC 26MM PYUNG
CHANG TP D
TIMER PWB DVD755VR /xx
Various
A49 9965 000 19245 VCR PHILIPS COMBI

C601 4822 124 11947 10µF 20% 16V
C602 9965 000 18600 470µF SR,SV 6.3V 20% FM5
TP 5
C603 9965 000 18674 0.022µF 50V Z F TA26 S
C611 9965 000 18624 1000P 50V K B TA26
C612 9965 000 18624 1000P 50V K B TA26

L601 9965 000 19251 820µH 5% 4X5 TR5
L602 9965 000 18648 100M K 2.3X3.4 L5 TP
L603 9965 000 18648 100M K 2.3X3.4 L5 TP

R601 9965 000 19230 1k Ω 1/6 W 5% TA26
R602 9965 000 19230 1k Ω 1/6 W 5% TA26
R603 9965 000 19230 1k Ω 1/6 W 5% TA26
R604 9965 000 19252 56k Ω 1/6 W 5% TA26
R605 9965 000 18652 330 Ω 1/6 W 5% TA26
R617 9965 000 19253 1.5k Ω 1/6 W 5% TA26
R618 9965 000 19254 1.2k Ω 1/6 W 5% TA26
R619 9965 000 19253 1.5k Ω 1/6 W 5% TA26
R620 9965 000 19253 1.5k Ω 1/6 W 5% TA26
R621 9965 000 19255 8.2k Ω 1/6 W 5% TA26
R641 9965 000 19256 75 Ω 1/6 W 5.00% TA26

DG601 9965 000 19246 11-MT-139GK FUTABA SEG
VFD COM
IC601 9965 000 19247 UPD16315GB-3BS NEC 44
QFP BK F

RC601 9322 155 82667 IR RECEIVER TSOP2236
SW60
8 9965 000 19257 THVV502GAA POSTECH
DC 12 V 5-
SW60
9 9965 000 19257 THVV502GAA POSTECH
DC 12 V 5-
SW61
0 9965 000 19257 THVV502GAA POSTECH
DC 12 V 5-
SW61
1 9965 000 19257 THVV502GAA POSTECH
DC 12 V 5-
KEY ASSY PWB DVD755VR /xx
Various
A42 9965 000 19258 VCR PHILIPS COMBI

R611 4822 116 52228 680Ω 5% 0,5W
R612 9965 000 19259 820 Ω 1/6 W 5% TA26
R613 9965 000 19254 1.2k Ω 1/6 W 5% TA26
R614 9965 000 19253 1.5k Ω 1/6 W 5% TA26
R615 9965 000 19260 2.2k Ω 1/6 W 5% TA26
R616 9965 000 19255 8.2k Ω 1/6 W 5% TA26
SW60
1 9965 000 19257 THVV502GAA POSTECH
DC 12 V 5-
SW60
2 9965 000 19257 THVV502GAA POSTECH
DC 12 V 5-
SW60
3 9965 000 19257 THVV502GAA POSTECH
DC 12 V 5-
SW60
4 9965 000 19257 THVV502GAA POSTECH
DC 12 V 5-
SW60
5 9965 000 19257 THVV502GAA POSTECH
DC 12 V 5-
SW60
6 9965 000 19257 THVV502GAA POSTECH
DC 12 V 5-
SW60
7 9965 000 19257 THVV502GAA POSTECH
DC 12 V 5-
VCR MECHANICAL DVD755VR /xx
Various
002 9965 000 19288 DRUM I2OAL05 SEJIN-
SANKYO ICLE
003 9965 000 19290 FPC(6CH)
004 9965 000 19291 FPC
008 9965 000 19292 P=1.25 FFC
UL2896(0.05X0.8) 7
009 9965 000 19293 T/UP(D35)
010 9965 000 19294 CHASSIS
011 9965 000 19295 TENSION(D35)
012 9965 000 19296 P2
013 9965 000 19297 P3
014 9965 000 19298 P4
015 9965 000 19299 LID(D35)
016 9965 000 19343 A/C HEAD (TDK)
017 9965 000 19300 S
018 9965 000 19301 COIL RS D35
019 9965 000 19302 RS
020 9965 000 19303 COIL D35 (TB)
021 9965 000 19304 T
022 9965 000 19305 D35 FE ST FE HEAD
023 9965 000 19306 LOADING
024 9965 000 19307 IDLER (H)
028 9965 000 19308 T
029 9965 000 19309 DECK/MECHA PINCH
030 9965 000 19310 T/UP
031 9965 000 19314 COIL TENSION(D35)
051 9965 000 19315 CAPSTAN
052 9965 000 19316 CAPSTAN F2QVB06
SANKYO D35 ASR
054 9965 000 19318 RACK F/L
055 9965 000 19320 DRIVE(D35)
056 9965 000 19321 CAM(D35)
058 9965 000 19322 CAPSTAN
060 9965 000 19323 F/R(D35)
061 9965 000 19324 D35 (M)
064 9965 000 19325 SECTOR(D35)
076 9965 000 19326 SPRING
077 9965 000 19327 SLIDER
078 9965 000 19328 TENSION
079 9965 000 19329 TENSION(D35)
100 9965 000 19330 TOP
102 9965 000 19333 COIL D35 (STOPPER)
109 9965 000 19334 DOOR
115 9965 000 19335 SWITCH
116 9965 000 19336 COIL D35 SWITCH
117 9965 000 19337 SPRING CST
401 9965 000 19338 D2.6 L4.5 MSWR3/FZY
402 9965 000 19339 D 2.6 L 4.0 MSWR3/FZY
405 9965 000 19340 + 1 D2.6 L5.8 SWRCH16A/
FZY TAP
406 4822 502 21655
409 9965 000 19341 + 1 D2.6 L5.0 SWRCH18A/
FZY TAP
410 9965 000 19342 D2.6 L6.8 MSWR3/FZY
A01 9965 000 19280 D35-6CH PAL (8P6C)
A04 9965 000 19281 L/D(S)
A11 9965 000 19282 P3
A12 9965 000 19283 P2
A21 9965 000 19284 CST
A22 9965 000 19285 RACK F/L
A23 9965 000 19286 F/L
A24 9965 000 19287 ASSY SWITCH
002A 9965 000 19289 ASSY D33 (TIP+2 SPRING)
1.4,
052A 9965 000 19317 CAPSTAN(D35)
054A 9965 000 19319 COIL D35 (RACK F/L)
100A 9965 000 19331 GND
100B 9965 000 19332 TOP(D35)
MECHANICAL DVD755VR /00
Various
250 9965 000 18503 CASE
260 9965 000 18504 FRAME
285 9965 000 18506 DOOR ASSEMBLY
300 9965 000 18507 POWER CORD
330 9965 000 18486
801 9965 000 19441 INSTRUCTION ASSEMBLY
900 9965 000 18509 REMOTE CONTROLLER
ASSEMBLY
FRONT PWB DVD755VR /00
Various
283 9965 000 18512 DOOR.CASE
284 4822 492 42785 SPRING DOOR
A43 9965 000 19443 PANEL
ASSEMBLY,FRONT[NORM
AL PA
SUB PWB DVD755VR /00
A46A 9965 000 19444 444503D7160F30 000000
00003000

C201 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C202 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C203 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C206 9965 000 18557 100µF SRA 16V M FM5
TP(5)
C207 4822 124 23056 47µF 20% 16V
C208 4822 124 23056 47µF 20% 16V
C211 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C212 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C213 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C214 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C231 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C232 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C233 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C234 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C239 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C240 3198 017 31530 0603 50V 15nF COL R
C241 4822 124 23056 47µF 20% 16V
C243 4822 126 12223 560pF 50V
C244 4822 126 12223 560pF 50V
C245 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C251 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C252 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C253 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C254 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C255 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C257 9965 000 18558 1µF 10V Z (F) 1508 R/TP
C258 9965 000 18558 1µF 10V Z (F) 1508 R/TP
C259 9965 000 18558 1µF 10V Z (F) 1508 R/TP
C260 9965 000 18558 1µF 10V Z (F) 1508 R/TP
C261 9965 000 18558 1µF 10V Z (F) 1508 R/TP
C262 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C263 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C264 3198 017 31530 0603 50V 15nF COL R
C265 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C266 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C267 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C268 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C269 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C270 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C271 9965 000 18559 390pF 50V J 1508 R/TP
C272 9965 000 18559 390pF 50V J 1508 R/TP
C273 9965 000 18560 0.033µF 50V K (X) 1508 R/
TP
C274 9965 000 18561 470pF 50V J 1508 R/TP
C276 9965 000 13794 SMD 10pF 5% 50V 0603
C277 3198 017 31530 0603 50V 15nF COL R
C278 4822 126 11669 27pF
C279 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C280 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C281 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C282 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C283 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C291 9965 000 18557 100µF SRA 16V M FM5
TP(5)
C292 4822 124 23056 47µF 20% 16V
