Philips DVD755VR - Page 142

Spare Parts Lists
EN 27DVD755VR 2.
C293 4822 124 23056 47µF 20% 16V
C295 4822 124 11947 10µF 20% 16V
C296 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C297 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C298 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C401 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C402 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C403 9965 000 18558 1µF 10V Z (F) 1508 R/TP
C404 9965 000 18558 1µF 10V Z (F) 1508 R/TP
C405 4822 124 23056 47µF 20% 16V
C406 9965 000 18557 100µF SRA 16V M FM5
TP(5)
C407 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C408 4822 124 40804 22µF 20% 63V
C409 4822 124 40804 22µF 20% 63V
C410 4822 124 40804 22µF 20% 63V
C411 4822 124 40804 22µF 20% 63V
C412 9965 000 18557 100µF SRA 16V M FM5
TP(5)
C413 5322 126 11578 1nF 10% 50V 0603
C414 5322 126 11578 1nF 10% 50V 0603
C415 9965 000 18562 270pF 50V 5% 1608 R/TP
C416 9965 000 18562 270pF 50V 5% 1608 R/TP
C417 9965 000 18562 270pF 50V 5% 1608 R/TP
C418 9965 000 18562 270pF 50V 5% 1608 R/TP
C419 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C420 9965 000 18557 100µF SRA 16V M FM5
TP(5)
C421 9965 000 18563 3900pF 50V K Z5U(E) 1608
R/TP
C422 9965 000 18563 3900pF 50V K Z5U(E) 1608
R/TP
C423 4822 124 40804 22µF 20% 63V
C424 4822 124 40804 22µF 20% 63V
C425 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C426 4822 124 12052 220µF 20% 6,3V
C502 5322 126 11583 10nF 10% 50V 0603
C503 5322 126 11583 10nF 10% 50V 0603
C504 5322 126 11583 10nF 10% 50V 0603
C505 5322 126 11583 10nF 10% 50V 0603
C506 9965 000 11253 CHIP 100P/50V (J) CH 0603
C507 5322 126 11583 10nF 10% 50V 0603
C508 9965 000 18564 2.2µF 16V 80%,-20% (F)
3216
C509 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C510 9965 000 11253 CHIP 100P/50V (J) CH 0603
C511 4822 124 23056 47µF 20% 16V
C513 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C514 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C515 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C516 9965 000 18564 2.2µF 16V 80%,-20% (F)
3216
C517 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C518 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C519 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C520 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C521 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C522 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C523 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C524 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C525 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C526 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C527 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C528 4822 124 23056 47µF 20% 16V
C530 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C531 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C532 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C533 4822 126 14507 18pF 5% 50V 0603
C534 2222 867 15339 0603 50V 33P 5%
C535 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C536 5322 126 11578 1nF 10% 50V 0603
C537 5322 126 11578 1nF 10% 50V 0603
C538 5322 126 11578 1nF 10% 50V 0603
C539 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C540 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C541 4822 124 11947 10µF 20% 16V
C542 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C543 4822 124 11947 10µF 20% 16V
C544 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C545 4822 124 11947 10µF 20% 16V
C554 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C555 4822 124 11947 10µF 20% 16V
C556 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C557 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C558 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C559 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C560 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C561 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C563 4822 124 12052 220µF 20% 6,3V
C564 4822 124 12052 220µF 20% 6,3V
C567 4822 126 13883 220pF 5% 50V
C568 4822 126 13883 220pF 5% 50V
C569 4822 126 13883 220pF 5% 50V
C575 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C576 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C577 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C578 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C579 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C580 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C581 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C582 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C583 4822 124 12052 220µF 20% 6,3V
C584 4822 126 11669 27pF
C585 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C586 9965 000 11253 CHIP 100P/50V (J) CH 0603
C587 9965 000 11253 CHIP 100P/50V (J) CH 0603
C589 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C590 4822 124 12052 220µF 20% 6,3V
C591 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C592 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C597 4822 126 11785 0603 50V 47P 5%
C5A1 4822 124 11947 10µF 20% 16V
C5A2 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C5C1 4822 124 23056 47µF 20% 16V
C5C2 4822 124 23053 1µF 20% 63V
C5C4 4822 124 23053 1µF 20% 63V
C5C5 4822 124 23053 1µF 20% 63V
C5C6 4822 124 23053 1µF 20% 63V
C5C7 4822 124 23053 1µF 20% 63V
C5C8 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C5C9 4822 124 40804 22µF 20% 63V
C5E0 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C601 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C602 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C603 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C604 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C605 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP
C606 9965 000 18556 0.1µF 50V Z (F) 1508 R/TP

D401 4822 130 80522 DAP202U
D601 9965 000 18565 RL104F TP RECTRON NON
400V 1A
F501 9965 000 18566 LFA20-2A1E473MT
MITSUBISHI MAT

L201 9965 000 18574 10µH 5% 4X5 TR5
L202 9965 000 18575 HB-1M2012-102JT
CERATECH TP
L203 9965 000 18574 10µH 5% 4X5 TR5
L204 9965 000 18575 HB-1M2012-102JT
CERATECH TP
L231 9965 000 18575 HB-1M2012-102JT
CERATECH TP
L251 9965 000 18575 HB-1M2012-102JT
CERATECH TP
L261 9965 000 18575 HB-1M2012-102JT
CERATECH TP
L262 9965 000 18575 HB-1M2012-102JT
CERATECH TP
L264 9965 000 18575 HB-1M2012-102JT
CERATECH TP
L265 9965 000 18575 HB-1M2012-102JT
CERATECH TP
L401 9965 000 18575 HB-1M2012-102JT
CERATECH TP
L402 9965 000 18575 HB-1M2012-102JT
CERATECH TP
L403 9965 000 18575 HB-1M2012-102JT
CERATECH TP
L501 9965 000 18575 HB-1M2012-102JT
CERATECH TP
L502 9965 000 18575 HB-1M2012-102JT
CERATECH TP
L503 9965 000 18575 HB-1M2012-102JT
CERATECH TP
L504 9965 000 18575 HB-1M2012-102JT
CERATECH TP
L505 9965 000 18575 HB-1M2012-102JT
CERATECH TP
L506 9965 000 18575 HB-1M2012-102JT
CERATECH TP
L507 9965 000 18575 HB-1M2012-102JT
CERATECH TP
L508 9965 000 18575 HB-1M2012-102JT
CERATECH TP
L5C1 9965 000 18575 HB-1M2012-102JT
CERATECH TP
L601 9965 000 18575 HB-1M2012-102JT
CERATECH TP
L602 9965 000 18575 HB-1M2012-102JT
CERATECH TP
L613 9965 000 18575 HB-1M2012-102JT
CERATECH TP

Q201 4822 130 10491 KTC3875S-GR-T1(ALG)
Q202 3141 018 51690 TRA SM 2SK3018
Q203 3141 018 51690 TRA SM 2SK3018
Q204 4822 130 61269 2SA1037KQ
Q205 4822 130 61269 2SA1037KQ
Q401 4822 130 61269 2SA1037KQ
Q404 9965 000 11427 KRA103S (SOP)
Q405 9965 000 11427 KRA103S (SOP)
Q501 4822 130 10491 KTC3875S-GR-T1(ALG)

R201 4822 051 30103 10k 5% 0,062W
R202 4822 117 13632 100k 1% 0603 0.62W
R203 4822 051 30103 10k 5% 0,062W
R204 4822 117 13632 100k 1% 0603 0.62W
R205 2322 702 60279 RST SM 0603 RC21 27Ω
PM5 R
R206 2322 702 60279 RST SM 0603 RC21 27Ω
PM5 R
R207 4822 051 30008 0Ω jumper
R208 4822 051 30008 0Ω jumper
R209 4822 051 30008 0Ω jumper
R210 4822 051 30008 0Ω jumper
R211 4822 117 13613 2Ω2 5% 0603
R212 9965 000 18576 750k Ω 1/16 W 5% 1608 R/
TP
R213 9965 000 18577 390k Ω 1 / 16 W 1608 5.00%
D
R214 9965 000 18576 750k Ω 1/16 W 5% 1608 R/
TP
R215 9965 000 18577 390k Ω 1 / 16 W 1608 5.00%
D
R216 9965 000 18578 1 Ω 1 / 16 W 1608 5.00% D
R217 4822 117 13613 2Ω2 5% 0603
R218 4822 117 13613 2Ω2 5% 0603
R220 2322 702 60279 RST SM 0603 RC21 27Ω
PM5 R
R221 2322 702 60279 RST SM 0603 RC21 27Ω
PM5 R
R231 4822 051 30222 2k2 5% 0,062W
R232 4822 051 30222 2k2 5% 0,062W
R233 4822 117 13613 2Ω2 5% 0603
R234 4822 117 13613 2Ω2 5% 0603
R235 4822 051 30103 10k 5% 0,062W
R236 4822 051 30153 15k 5% 0,062W
R237 4822 051 30273 27k 5% 0,062W
R238 4822 051 30103 10k 5% 0,062W
R239 4822 051 30103 10k 5% 0,062W
R240 4822 051 30103 10k 5% 0,062W
R241 4822 051 30103 10k 5% 0,062W
R242 4822 051 30273 27k 5% 0,062W
R243 4822 051 30103 10k 5% 0,062W
R244 4822 051 30153 15k 5% 0,062W
R245 4822 051 30103 10k 5% 0,062W
R246 4822 051 30103 10k 5% 0,062W
R251 4822 051 30333 33k 5% 0,062W
R252 4822 117 13632 100k 1% 0603 0.62W
R253 4822 051 30273 27k 5% 0,062W
R254 4822 051 30008 0Ω jumper
R255 4822 051 30008 0Ω jumper
R256 4822 051 30103 10k 5% 0,062W
R257 4822 051 30103 10k 5% 0,062W
R258 4822 051 30008 0Ω jumper
R259 4822 051 30008 0Ω jumper
R401 4822 051 30102 1k 5% 0,062W
R402 4822 051 30008 0Ω jumper
R403 4822 051 30008 0Ω jumper
R404 4822 051 30008 0Ω jumper
R405 4822 051 30008 0Ω jumper
R407 4822 051 30562 5k6 5% 0,063W 0603 RC21
RST SM
R408 2322 702 60752 RST SM 0603 RC21 7k5
PM5 R
R409 2322 702 60752 RST SM 0603 RC21 7k5
PM5 R
R410 2322 702 60752 RST SM 0603 RC21 7k5
PM5 R
R411 2322 702 60752 RST SM 0603 RC21 7k5
PM5 R
R412 4822 117 12902 8k2 1% 0.063W 0603
R413 4822 117 12903 1k8 1% 0.063W 0603
R414 4822 117 12903 1k8 1% 0.063W 0603
R415 4822 117 12902 8k2 1% 0.063W 0603
R416 4822 117 12903 1k8 1% 0.063W 0603
R417 4822 051 30472 4k7 5% 0,062W
R418 4822 117 12902 8k2 1% 0.063W 0603
