Philips DVD755VR - Page 143

Spare Parts Lists
EN 28 DVD755VR2.
R419 4822 117 12902 8k2 1% 0.063W 0603
R420 4822 117 12903 1k8 1% 0.063W 0603
R421 4822 051 30331 330Ω 5% 0,062W
R422 4822 051 30331 330Ω 5% 0,062W
R423 4822 051 30102 1k 5% 0,062W
R424 4822 051 30102 1k 5% 0,062W
R425 4822 051 30102 1k 5% 0,062W
R426 4822 051 30102 1k 5% 0,062W
R427 4822 051 30102 1k 5% 0,062W
R501 4822 117 12902 8k2 1% 0.063W 0603
R502 9965 000 18576 750k Ω 1/16 W 5% 1608 R/
TP
R503 9965 000 18579 4.7 Ω 1 / 16 W 1608 5.00% D
R504 4822 051 30008 0Ω jumper
R505 9965 000 18579 4.7 Ω 1 / 16 W 1608 5.00% D
R506 9965 000 18579 4.7 Ω 1 / 16 W 1608 5.00% D
R507 4822 051 30152 1k5 5% 0,062W
R508 4822 117 13632 100k 1% 0603 0.62W
R509 4822 051 30008 0Ω jumper
R510 4822 051 30008 0Ω jumper
R511 4822 051 30183 18k 5% 0,062W
R512 4822 117 13632 100k 1% 0603 0.62W
R513 4822 051 30008 0Ω jumper
R515 4822 051 30339 33Ω 5% 0,062W
R516 4822 051 30339 33Ω 5% 0,062W
R517 4822 051 30339 33Ω 5% 0,062W
R518 4822 051 30339 33Ω 5% 0,062W
R519 4822 051 30339 33Ω 5% 0,062W
R520 4822 051 30339 33Ω 5% 0,062W
R521 4822 051 30339 33Ω 5% 0,062W
R522 4822 051 30339 33Ω 5% 0,062W
R523 9965 000 18580 1.2k Ω 1 / 16 W 1608 5.00%
D
R524 9965 000 18580 1.2k Ω 1 / 16 W 1608 5.00%
D
R525 9965 000 18580 1.2k Ω 1 / 16 W 1608 5.00%
D
R526 4822 051 30101 100Ω 5% 0,062W
R527 4822 051 30472 4k7 5% 0,062W
R528 9965 000 18580 1.2k Ω 1 / 16 W 1608 5.00%
D
R529 4822 051 30008 0Ω jumper
R534 4822 051 30102 1k 5% 0,062W
R535 4822 051 30102 1k 5% 0,062W
R564 4822 051 30183 18k 5% 0,062W
R565 4822 051 30183 18k 5% 0,062W
R566 4822 051 30103 10k 5% 0,062W
R567 4822 051 30103 10k 5% 0,062W
R570 4822 051 30008 0Ω jumper
R573 4822 051 30221 220Ω 5% 0,062W
R574 4822 051 30221 220Ω 5% 0,062W
R577 4822 051 30471 470Ω 5% 0,062W
R578 4822 051 30101 100Ω 5% 0,062W
R579 4822 051 30102 1k 5% 0,062W
R580 4822 051 30102 1k 5% 0,062W
R581 4822 051 30102 1k 5% 0,062W
R584 4822 117 12139 22Ω 5% 0,062W
R585 9965 000 18581 110 Ω 1 / 16 W 1608 5.00% D
R586 4822 051 30759 75Ω 5% 0,062W
R587 9965 000 18581 110 Ω 1 / 16 W 1608 5.00% D
R5A7 4822 051 30103 10k 5% 0,062W
R5A9 4822 051 30102 1k 5% 0,062W
R5C1 4822 051 30151 150Ω 5% 0,062W
R5C3 4822 051 30151 150Ω 5% 0,062W
R5C4 4822 051 30151 150Ω 5% 0,062W
R5C5 4822 051 30151 150Ω 5% 0,062W
R5C6 4822 051 30151 150Ω 5% 0,062W
R5C9 4822 051 30008 0Ω jumper
R5E1 4822 051 30008 0Ω jumper
R601 4822 051 30759 75Ω 5% 0,062W
R602 4822 051 30759 75Ω 5% 0,062W
R603 4822 051 30759 75Ω 5% 0,062W
R604 4822 051 30759 75Ω 5% 0,062W
R605 4822 051 30759 75Ω 5% 0,062W
R606 4822 051 30759 75Ω 5% 0,062W
R607 4822 051 30008 0Ω jumper
R608 4822 051 30008 0Ω jumper
R609 4822 051 30008 0Ω jumper
R610 4822 051 30008 0Ω jumper
R611 4822 051 30008 0Ω jumper
X501 9965 000 18582 HC-49/S BUBANG 27MHz
20PPM 1
IC201 9965 000 18567 MT1336E MEDIATEK
INCORPORATION
IC202 9965 000 18568 LA6560-A-TE-L SANYO
HSOP-36R R
IC401 9965 000 11006 CS4391 TSSOP20
IC402 9965 000 04714 IC NJM4580M
IC501 9965 000 18569 MT1379DE MEDIATEK
INCORPORATIO
IC502 9965 000 18570 M12L16161A-7T-TI ELITE
MEMORY
IC503 9965 000 18570 M12L16161A-7T-TI ELITE
MEMORY
IC505 9965 000 18571 S524A40X21-SCT0 SOP8
TP EEPROM
IC510 9965 000 18554 MM74HCT244SJ 20P SOIC
TP 3-STA
IC5C1 9965 000 18573 MM1623XFBE MITSUMI
28PIN SOP R
ZD501 4822 130 83206 BZX79-B5V6
MAIN PWB DVD755VR /00
Various
323 9965 000 18584 VCR - PRE-AMP (02-PAL)
A46 9965 000 19445 VCR VP600CIK NA4UPP
BC91 9965 000 18585 BEAD CORE
BFS3550R2FD8,R T/P
BC92 9965 000 18585 BEAD CORE
BFS3550R2FD8,R T/P

C216 4822 051 20008 0R00 JUMP. ()
C301 4822 124 11947 10µF 20% 16V
C302 4822 124 40804 22µF 20% 63V
C303 9965 000 18591 1800pF 50V 10% B(5YP)
2012 R/T
C304 4822 124 23056 47µF 20% 16V
C305 9965 000 18586 0.01µF 50V 5% B(5YP) 2012
R/TP
C306 9965 000 18592 1200P 50V K B 2.0X1.25 R/
TP
C307 4822 124 23053 1µF 20% 63V
C308 9965 000 18593 0.015µF 50V K B 2.0X1.2 R/
TP
C309 9965 000 18594 220P 50V J 2.0X1.25 R/TP
C310 9965 000 18586 0.01µF 50V 5% B(5YP) 2012
R/TP
C311 9965 000 18595 47µF SR,SV 50V M FL TP 5
C312 9965 000 18586 0.01µF 50V 5% B(5YP) 2012
R/TP
C313 9965 000 18596 0.022µF S 63V K PP NI TP5
C314 4822 124 11947 10µF 20% 16V
C315 9965 000 18590 2.2µF SRA,SS 50V 20% FM5
TP 5
C316 4822 124 11947 10µF 20% 16V
C317 9965 000 18586 0.01µF 50V 5% B(5YP) 2012
R/TP
C318 4822 124 23053 1µF 20% 63V
C319 9965 000 18586 0.01µF 50V 5% B(5YP) 2012
R/TP
C320 4822 124 23053 1µF 20% 63V
C321 4822 126 13694 68pF 1% 63V
C322 4822 124 11947 10µF 20% 16V
C323 4822 124 11947 10µF 20% 16V
C324 4822 124 40769 4,7µF 20% 100V
C325 4822 124 11947 10µF 20% 16V
C326 9965 000 18586 0.01µF 50V 5% B(5YP) 2012
R/TP
C327 4822 124 23053 1µF 20% 63V
C328 9965 000 18586 0.01µF 50V 5% B(5YP) 2012
R/TP
C329 9965 000 18586 0.01µF 50V 5% B(5YP) 2012
R/TP
C330 9965 000 18587 0.1µF 2012 50V 80%,-20%
(F)
C331 4822 124 40804 22µF 20% 63V
C333 4822 124 23056 47µF 20% 16V
C334 9965 000 18586 0.01µF 50V 5% B(5YP) 2012
R/TP
C335 9965 000 18586 0.01µF 50V 5% B(5YP) 2012
R/TP
C336 4822 124 23056 47µF 20% 16V
C337 4822 124 23053 1µF 20% 63V
C338 4822 126 13751 47nF 10% 63V
C339 4822 124 23053 1µF 20% 63V
C340 4822 126 13751 47nF 10% 63V
C341 9965 000 18597 0.022µF 50V K B 2.0X1.2 R/
TP
C342 9965 000 18587 0.1µF 2012 50V 80%,-20%
(F)
C343 4822 126 13751 47nF 10% 63V
C345 9965 000 18598 0.056µF 50V 10% B(5YP)
2012 R/
C346 4822 124 23056 47µF 20% 16V
C347 4822 124 23053 1µF 20% 63V
C348 4822 124 23053 1µF 20% 63V
C349 4822 124 23056 47µF 20% 16V
C350 9965 000 18587 0.1µF 2012 50V 80%,-20%
(F)
C351 9965 000 18594 220P 50V J 2.0X1.25 R/TP
C353 4822 124 23053 1µF 20% 63V
C355 9965 000 18587 0.1µF 2012 50V 80%,-20%
(F)
C356 4822 124 23053 1µF 20% 63V
C357 4822 124 23053 1µF 20% 63V
C358 4822 126 13694 68pF 1% 63V
C359 4822 124 23053 1µF 20% 63V
C361 9965 000 18597 0.022µF 50V K B 2.0X1.2 R/
TP
C362 4822 124 23056 47µF 20% 16V
C363 9965 000 18586 0.01µF 50V 5% B(5YP) 2012
R/TP
C366 9965 000 18586 0.01µF 50V 5% B(5YP) 2012
R/TP
C367 9965 000 18587 0.1µF 2012 50V 80%,-20%
(F)
C368 9965 000 18599 8200P 50V K B 2.0X1.2 R/TP
C369 4822 126 13221 100pF 2% 63V
C370 4822 126 13695 82pF 1% 63V
C371 4822 126 13695 82pF 1% 63V
C372 4822 126 13695 82pF 1% 63V
C374 9965 000 18587 0.1µF 2012 50V 80%,-20%
(F)
C375 9965 000 18587 0.1µF 2012 50V 80%,-20%
(F)
C376 9965 000 18587 0.1µF 2012 50V 80%,-20%
(F)
C377 9965 000 18587 0.1µF 2012 50V 80%,-20%
(F)
C500 9965 000 18600 470µF SR,SV 6.3V 20% FM5
TP 5
C501 9965 000 18587 0.1µF 2012 50V 80%,-20%
(F)
C502 4822 124 23056 47µF 20% 16V
C503 4822 124 12052 220µF 20% 6,3V
C504 4822 124 12052 220µF 20% 6,3V
C505 4822 124 23056 47µF 20% 16V
C506 9965 000 18597 0.022µF 50V K B 2.0X1.2 R/
TP
C508 9965 000 18587 0.1µF 2012 50V 80%,-20%
(F)
C509 9965 000 18601 22P 50V J 2.0X1.2 R/TP
C511 9965 000 18587 0.1µF 2012 50V 80%,-20%
(F)
C512 9965 000 18602 1000P 50V K B 2.0X1.25 R/
TP
C513 9965 000 18602 1000P 50V K B 2.0X1.25 R/
TP
C514 9965 000 18603 12pF 50V 5% 2012 R/TP
C515 9965 000 18604 15P 50V J COG 2.0X1.2 R/
TP
C516 9965 000 18597 0.022µF 50V K B 2.0X1.2 R/
TP
C518 9965 000 18605 0.01µF 50V K B 2.0X1.25 R/
TP
C519 9965 000 18587 0.1µF 2012 50V 80%,-20%
(F)
C520 9965 000 18602 1000P 50V K B 2.0X1.25 R/
TP
C521 9965 000 18602 1000P 50V K B 2.0X1.25 R/
TP
C523 9965 000 18590 2.2µF SRA,SS 50V 20% FM5
TP 5
C524 4822 124 23056 47µF 20% 16V
C525 9965 000 18606 1µF 16V Z (F) 2012 R/TP
C526 9965 000 18607 47µF SRA,SS 35V M FM5 TP
5
C527 9965 000 18594 220P 50V J 2.0X1.25 R/TP
C533 9965 000 18602 1000P 50V K B 2.0X1.25 R/
TP
C534 4822 124 40769 4,7µF 20% 100V
C535 9965 000 18606 1µF 16V Z (F) 2012 R/TP
C543 9965 000 18608 2200P 50V K B 2.0X1.25 R/
TP
C544 9965 000 18609 0.047µF 50V Z (F) 2012 R/TP
C545 9965 000 18610 0.033µF 25V K B 2.0X1.25 R/
TP
C546 9965 000 18607 47µF SRA,SS 35V M FM5 TP
5
C547 9965 000 18605 0.01µF 50V K B 2.0X1.25 R/
TP
C551 9965 000 18610 0.033µF 25V K B 2.0X1.25 R/
TP
C552 9965 000 18605 0.01µF 50V K B 2.0X1.25 R/
TP
C561 4822 124 12052 220µF 20% 6,3V
C564 9965 000 18602 1000P 50V K B 2.0X1.25 R/
TP
C567 9965 000 18602 1000P 50V K B 2.0X1.25 R/
TP
C570 9965 000 18604 15P 50V J COG 2.0X1.2 R/
TP
C571 9965 000 18604 15P 50V J COG 2.0X1.2 R/
TP
