Diagnostic Software
EN 32 DVDR615/695.
Basic Engine (BE)
Nucleus Name DS_PSCAN_DevTypeGetDeinterlacer
Nucleus Number 807
Description Get the device (revision) type information of the progressive scan de-interlacer.
Technical - Initialise the dei-nterlacer.
- Read the version register of the de-interlacer.
Execution Time 1 second
User Input None
Error Number Description
80700 Everything went well.
80701 The communication with the device failed
80702 No chip was expected
Example DS:> 807
080700:
Chip name : 2300
Chip version : 1
Test OK @
Nucleus Name DS_PSCAN_CommunicationDeinterlacer
Nucleus Number 808
Description Check the communication between the IIC controller of the Codec and the progressive
scan De-interlacer-IC
Technical - Initialise IIC
- Set the video source synchronisation source to the Codec
- Write data to the DENC through IIC
Execution Time Less than 1 second
User Input None
Error Number Description
80800 Communicating with the progressive scan De-interlacer-IC
succeeded
80801 The IIC bus was not accessible
80802 There was a timeout reading the device
80803 The communication with the device failed (no ACK)
80804 Communicating with the progressive scan De-interlacer-IC
failed
80805 The initialisation of the IIC bus failed
80806 The data read back is not the same as the data written
80807 No chip was expected
Example DS:> 808
080800:
Test OK @
Nucleus Name DS_BE_CommunicationEcho
Nucleus Number 900
Description Check the communication between the digital board and the basic engine by issuing an
echo command
Technical - Send the ECHO command
- Check if the BE returned the string 0x00 0xAA 0x55
Execution Time Less than 1 second
User Input None
Error Number Description
90000 Communicating with the BE over the S2B interface succeed-
ed
90001 There was a time-out while communicating
90002 The Basic Engine returned an unexpected result
90003 The Basic Engine returned an error code
90004 No acknowledge received from BE
90005 Communicating with the Basic Engine failed
90006 Echo check failed, no echo received
90007 Echo check failed, received wrong pattern
Example DS:> 900
090000:
Test OK @
