Diagnostic Software
EN 33DVDR615/69 5.
Nucleus Name DS_BE_Reset
Nucleus Number 901
Description Reset the basic engine
Technical - Check if an AV2 or AV3 is connected
- In case of an AV2 Toggle the reset pin of the I2S interface
- In case of an AV3 Toggle the reset pin of the IDE interface
Execution Time 2 seconds on AV2
9 seconds on AV3 (when disc inside)
User Input None
Error Number Description
90100 Resetting the Basic Engine succeeded
90101 Resetting the Basic Engine failed
Example DS:> 901
090100:
Test OK @
Nucleus Name DS_BE_GetSelftestResult
Nucleus Number 902
Description Return the self-test results through the service port
Technical - Check if an AV2 or AV3 is connected
- In case of an AV2 Send the S2B GET_SELF_TEST_RESULT command
- In case of an AV3 Send the ATAPI REPORT_DRIVE_DIAGNOSTICS command
- On error display the specific error codes received from the BE
Execution Time Less than 1 second
User Input None
Error Number Description
90200 Self test succeeded, no errors
90201 There was a time-out while communicating
90202 The Basic Engine returned an unexpected result
90203 The BE returned an error code
90204 No acknowledge received from BE
90205 Communicating with the Basic Engine failed
90206 Basic Engine returned no info
90207 Self test failed, errors are echoed
Example DS:> 902
090200:
Self-test result byte : 00000000
Self-test result byte : 00000000
Self-test result byte : 00000000
Test OK @
Nucleus Name DS_BE_VersionGet
Nucleus Number 903
Description Get the version of the basic engine and that of the optical unit
Technical - Check if an AV2 or AV3 is connected
- In case of an AV2 send the S2B GET_VERSION_NUMBER command
- In case of an AV3 send the ATAPI INQUIRY command
- Send the GET_OPU_VERSION command
- Display the returned version information
Execution Time Less than 1 second
User Input None
Error Number Description
90300 BE version OK
90301 There was a time-out while communicating
90302 The Basic Engine returned an unexpected result
90303 The BE returned an error code
90304 No acknowledge received from BE
90305 Communicating with the Basic Engine failed
90306 The BE returned no info
Example DS:> 903
090300:
BE version = 31.30.24. PHILIPS ,VAD8031 ,31302400,REL_8031_313024 2073,
Optical unit version = 00.06.82.19.00
Test OK @
