Philips DVDR615 - Page 38

Diagnostic Software
EN 38 DVDR615/695.
Error Number Description
91200 Optimising jitter succeeded
91201 There was a time-out while communicating
91202 The Basic Engine returned an unexpected result
91203 The Basic Engine returned an error code
91204 No acknowledge received from BE
91205 Unable to send tray in
91206 Unable to read the disc
91207 No disc is loaded
91208 Unknown disc is loaded
91209 Unable to enter service mode
Example (AV2) DS:> 912
091200: Jitter bathtub: (-42,135)(-40,127)(-38,106)(-36,106)(-34,101)(-32,97)(-30,92)(-
28,92)(-26,92)(-24,92)(-22,86)(-20,80)(-18,86)(-16,86)(-14,80)(-12,80)(-10,80)(-8,80)(-
6,80)(-4,86)(-
2,86)(0,86)(2,86)(4,92)(6,92)(8,101)(10,106)(12,111)(14,120)(16,123)(18,127)(20,142)
Test OK @
Example (AV3) DS:> 912
091200: Average Jitter, Bler C1, Bler C2: (92,4,254)
Test OK @
Nucleus Name DS_BE_FocusOn
Nucleus Number 913
Description Put the laser of the BE into focus
Technical - Check if an AV2 or AV3 is connected
- In case of an AV2 Send the FOCUS command with parameter 0x01
- In case of an AV3 Send the transparent BIT engine FOCUS command
Execution Time 3 seconds
User Input None
Error Number Description
91300 Focus on succeeded
91301 There was a time-out while communicating
91302 The Basic Engine returned an unexpected result
91303 The BE returned an error code
91304 No acknowledge received from BE
91305 Communicating with the Basic Engine failed
91306 Unable to enter service mode
Example DS:> 913
091300:
Test OK @
Nucleus Name DS_BE_FocusOff
Nucleus Number 914
Description Turn off putting the laser of the BE into focus
Technical - Check if an AV2 or AV3 is connected
- In case of an AV2 Send the FOCUS command with parameter 0x00
- In case of an AV3 Send the transparent BIT engine FOCUS command
Execution Time Less than 1 second on AV2
2 seconds on AV3
User Input None
Error Number Description
91400 Focus off succeeded
91401 There was a time-out while communicating
91402 The Basic Engine returned an unexpected result
91403 The BE returned an error code
91404 No acknowledge received from BE
91405 Communicating with the Basic Engine failed
91406 Unable to enter service mode
Example DS:> 914
091400:
Test OK @
Nucleus Name DS_BE_MotorOn
Nucleus Number 915
