Philips DVDR615 - Page 53

Diagnostic Software
EN 53DVDR615/69 5.
Nucleus Name DS_SYS_DisplayFatalOff
Nucleus Number 1224
Description Turn off the display-fatal functionality which displays debug-information on the display
when encountering a fatal error condition from which could not be recovered
automatically
Technical Issue the command to stop using the display-fatal functionality to the analogue board
Execution Time Less than 1 second.
User Input None
Error Number Description
122400 Turning off the display-fatal functionality succeeded
122401 Turning off the display-fatal functionality failed
122402 The returned errorcode from the analogue board is
unknown:
122403 No DS errCode known for analogue board error:
122404 There was no response from the analogue board.
122405 Section validation or write failed in NVRAM
122406 Reading the section from NVRAM failed
122407 Initialisation of IIC or reaching NVRAM failed
Example DS:> 1224
122400:
Test OK @
Nucleus Name DS_SYS_DisplayFatalGet
Nucleus Number 1225
Description Get the display-fatal flag of the recorder
Technical Issue the command to get the status of the display-fatal functionality to the analogue
board
Execution Time Less than 1 second.
User Input None
Error Number Description
122500 Getting the display-fatal flag succeeded
122501 Getting the display-fatal flag failed
122502 The returned errorcode from the analogue board is
unknown:
122503 No DS errCode known for analogue board error:
122504 There was no response from the analogue board.
122505 Reading the display fatal flag failed
122506 Initialisation of IIC or reaching NVRAM failed
122507 Unexpected version read from NVRAM section
122508 Reading the fatal flag from NVRAM failed
Example DS:> 1225
122500: The Display Fatal functionality is ON
Test OK @
Nucleus Name DS_SYS_SettingsSet
Nucleus Number 1226
Description Programs the digital board settings into the boot EEPROM on the digital board.
Technical Evaluate user input. Set-up IIC-bus. Write data to boot EEPROM. Update checksum.
Execution Time 1 second
User Input A large hexadecimal value that represents the digital board settings obtained from the
XDIVTOOL.exe program or from a reference set.
Error Number Description
122600 The settings were successfully programmed.
122601 User input is invalid.
122602 IIC access failed.
Example DS:> 1226 646961677473746201010200010101010101000020080000
122600:
Test OK @
Nucleus Name DS_SYS_SettingsDisplay
Nucleus Number 1228
Description Show the settings that are programmed in the BROM on the digital board.
Technical Set-up IIC-bus. Read Digital Board Settings from boot EEPROM. Display the settings.
