Diagnostic Software
EN 54 DVDR615/695.
Execution Time 1 second
User Input None.
Error Number Description
122800 The settings were successfully displayed.
122801 IIC access failed.
122802 Invalid settings
Example DS:> 1228
Settings
ID:
444248491D9420014E46332B0000000029040303000101020001010040080800
Board name: NF3+
Hardware ID: 29
Codec IC: PNX7100_C2/C3
Video Input Processor IC: SAA7118
Progressive Scan Deinterlacer IC: S2301
Progressive Scan Denc IC: None
I-Link physical layer circuit IC: PDI1394P25
I-Link link layer circuit IC: PDI1394P40
Audio clock: Clock scheme 1
Bit engine connector: not available
IDE connector 1: available
IDE connector 2: available
PCI connector: not available
RAM size 64MByte
ROM size (NOR FLASH bank 1) 8MByte
ROM size (NOR FLASH bank 2) 8MByte
ROM size (NAND FLASH) Not available
Bit Engine: AV 3.1
122800:
Test OK @
Nucleus Name DS_SYS_SettingsGet
Nucleus Number 1229
Description Get the digital board diversity settings string that is programmed in the BROM on the
digital board.
Technical - Set-up IIC-bus.
- Read Digital Board Settings from boot EEPROM.
- Read System Settings from boot EEPROM.-Display the settings.
Execution Time 1 second
User Input None.
Error Number Description
122900 The settings were successfully displayed.
122901 IIC access failed.
122902 The settings are invalid
Example DS:> 1229
122900: 6D7920626F61726400020300010101020101000020080000
Test OK @
Nucleus Name DS_SYS_AudioLoopThroughStart
Nucleus Number 1230
Description Description: The audio input is routed from the input to all outputs. The input is set
routing the signal with the proper nucleus. All outputs are enabled.
Technical - Encode the audio to AC3 in memory
- Decode the AC3 in memory to audio on the outputs
Execution Time 1second buffer time and 30 seconds playing.
User Input None.
Error Number Description
123000 AudioLoopthroughStart succeeded
123001 Resetting the audio decoder failed
123002 Resetting the audio encoder failed
123003 Encoding the audio failed
123004 Decoding the audio failed
Example DS:> 1230
123000:
Test OK @
