Diagnostic Software
EN 64 DVDR615/695.
VIDEO MATRIX (VMIX)
170003 The IIC acknowledge was not received
170004 The communication with the device failed
170005 The IIC bus failed
170006 The IIC bus initialisation failed
Example DS:> 1700
170000:
Test OK @
Nucleus Name DS_VMIX_Communication
Nucleus Number 1800
Description This nucleus checks the communication between the IIC controller of the Codec and
the Video Matrix on the analogue board
Technical Try to read anything from the video matrix by means of IIC
Execution Time Less than 1 second.
User Input None
Error Number Description
180000 Communicating wit the Video Matrix succeeded
180001 An IIC-bus error occurred
180002 There was a timeout reading the device
180003 The IIC bus was not accessible
180004 The IIC acknowledge was not received
180005 There was an IIC error upon the stop-condition
180006 The IIC bus was chosen wrong
180007 The IIC functionality is not running
180008 An unknown error was returned
Example DS:> 1800
180000:
Test OK @
Nucleus Name DS_VMIX_Routing
Nucleus Number 1801
Description This nucleus performs the routing of the video signals in the set. It sets the video path
according to the user input.
Technical - Determine whether the set is NAFTA/APAC or EUROPE
- Switch the videomatrix according to the input specified by the user
Execution Time Less than 1 second.
User Input The user inputs the path Id of choice, as specified in tables below for Europe/NAFTA-
APAC
Error Number Description
180100 Routing the video path succeeded
180101 The user provided wrong input
180102 There was no response from the video matrix
180103 Could not retrieve region from analogue slave processor
Example DS:> 1801 00
180100:
Test OK @
