Philips DVDR615 - Page 65

Diagnostic Software
EN 65DVDR615/69 5.
Table 5-3 Available VIDEO path-Ids for EUROPE routing
Table 5-4 Available VIDEO path-Ids for NAFTA / APAC routing
AUDIO MATRIX (SOUND PROCESSOR) (AMIX)
EURO Path ID Description
( DbOut=Digital Board Output, DbIn = Digital Board Input )
00 DbOut-CVBS/YC/RGB to RearOut-CVBS/YC and Scart_1-RGB.
01 - DbOut-CVBS to RearOut-CVBS.
- FrontIn-CVBS to DbIn-CVBS.
02 - DbOut-YC to RearOut-YC.
- FrontIn-YC to DbIn-YC.
03 - DbOut-CVBS to Scart_1-CVBS.
- Scart_2-CVBS to DbIn-CVBS.
04 - DbOut-YC to Scart_1-YC.
- Scart_2-YC to DbIn-YC.
05 - DbOut-RGB to Scart_1-RGB.
- Scart_2-RGB to DbIn-RGB.
06 - DbOut-CVBS to RearOut-CVBS.
- Tuner-CVBS to DbIn-CVBS.
07 DbOut-CVBS to DbIn-CVBS.
08 DbOut-PSCAN to RearOut-YUV.
09 DbOut-YUV to RearOut-YUV.
10 - DbOut-CVBS to Scart_2-CVBS.
- Scart_1-CVBS to DbIn-CVBS.
11 - DbOut-YC to Scart_2-YC.
- Scart_1-YC to DbIn-YC.
12 Scart_2-RGB to Scart_1-RGB.
13 Scart_2-CVBS to Scart_1-CVBS.
14 Scart_1-CVBS to Scart_2-CVBS.
NAFTA Path ID Description
( DbOut=Digital Board Output, DbIn = Digital Board Input )
00 DbOut-CVBS/YC/YUV to RearOut-CVBS/YC/YUV.
01 - DbOut-CVBS to RearOut-CVBS.
- FrontIn-CVBS to DbIn-CVBS.
02 - DbOut-YC to RearOut-YC.
- FrontIn-YC to DbIn-YC.
03 - DbOut-CVBS to RearOut-CVBS.
- RearIn-CVBS to DbIn-CVBS.
04 - DbOut-YC to RearOut-YC.
- RearIn-YC to DbIn-YC.
05 - DbOut-YUV to RearOut-YUV.
- RearIn-YUV to DbIn-YUV.
06 - DbOut-CVBS to RearOut-CVBS.
- Tuner-CVBS to DbIn-CVBS.
07 DbOut-CVBS to DbIn-CVBS.
08 DbOut-PSCAN to RearOut-YUV.
Nucleus Name DS_AMIX_Communication
Nucleus Number 1900
Description This nucleus checks the communication between the IIC controller of the Codec and
the Audio Matrix ( sound processor ) on the analogue board
Technical Test whether anything can be read from the sound processor
Execution Time Less than 1 second.
User Input None
Error Number Description
190000 Communicating wit the Audio Matrix succeeded
190001 An IIC-bus error occurred
190002 There was a timeout reading the device
190003 The IIC bus was not accessible
190004 The IIC acknowledge was not received
190005 There was an IIC error upon the stop-condition
190006 The IIC bus was chosen wrong
190007 The IIC functionality is not running
