EN 66 DVDR615/695.
Table 5-5
Available AUDIO path-Ids for EUROPE routing
Table 5-6 Available AUDIO path-Ids for NAFTA/APAC routing
190008 An unknown error was returned
Example DS:> 1900
190000:
Test OK @
Nucleus Name DS_AMIX_Routing
Nucleus Number 1901
Description This nucleus performs the routing of the audio signals in the set. It sets the audio path
according to the user input.
Technical - Determine whether the set is of type NAFTA-APAC or EUROPE
- Parse the user input to determine the routing
- According to parameters set the sound processor and multiplexers
Execution Time Less than 1 second.
User Input The user inputs the path ID of his/her choice, as specified in tables below for Europe/
NAFTA
Error Number Description
190100 Routing the audio path succeeded
190101 Routing the audio path failed
190102 There was an error resetting the sound processor
190103 The user provided wrong input
190104 There was no response from the ASP
Example DS:> 1901 00
190100:
Test OK @
EURO Path ID Description
( DbOut=Digital Board Output, DbIn = Digital Board Input )
00 DbOut to All Outs.
01 - DbOut to RearOut for CVBS/YC, and RearOut for YUV.
- FrontIn to DbIn.
02 - DbOut to Scart_1-AOut.
- Scart_2-AIn to DbIn.
03 - DbOut to Scart_2-AOut.
- Scart_1-AIn to DbIn.
04 - DbOut to RearOut for CVBS/YC.
- Tuner to DbIn.
05 DbOut to RearOut-5.1.
06 DbOut to DbIn
07 Scart_2-AIn to Scart_1-AOut.
08 Scart_1-AIn to Scart_2-AOut.
NAFTA Path ID Description
( DbOut=Digital Board Output, DbIn = Digital Board Input )
00 DbOut to All Outputs.
01 - DbOut to RearOut for CVBS/YC, and RearOut for YUV.
- FrontIn to DbIn.
02 - DbOut to RearOut for CVBS/YC, and RearOut for YUV.
- RearIn1 ( EXT2 ) for CVBS/YC to DbIn.
03 - DbOut to RearOut for CVBS/YC, and RearOut for YUV.
- RearIn2 ( EXT1) for YUV to DbIn.
04 - DbOut to RearOut for CVBS/YC, and RearOut for YUV.
- Tuner to DbIn.
05 DbOut to RearOut-5.1.
06 DbOut to DbIn.
Nucleus Name DS_AMIX_VersionGet
Nucleus Number 1902
Description This nucleus gets the version information from the sound processor.
Technical Read the information from the sound processor using IIC
Execution Time Less than 1 second
User Input -
