9A-16
ELECTRICAL PARTS LIST - ETF7 DOLBY BOARD
9A-16
RESISTORS
3745 482205120392 3k9 5% 0,1W
3746 482205120392 3k9 5% 0,1W
3748 482211711449 2k2 1% 0,1W
3749 482211710834 47k 1% 0,1W
3751 482211710833 10k 1% 0,1W
3752 482211710837 100k 1% 0,1W
3753 482211710837 100k 1% 0,1W
3754 482205120333 33k 5% 0,1W
3756 482211713579 220k 1% 0,1W
3757 482211713579 220k 1% 0,1W
3758 482211710833 10k 1% 0,1W
3759 482211710833 10k 1% 0,1W
3760 482205120121 120R 5% 0,1W
3761 482205021003 10k 1% 0,6W
3762 482211711454 820R 1% 0,1W
3763 482205120154 150k 5% 0,1W
3764 482211683872 220R 5% 0,5W
3765 482205120393 39k 5% 0,1W
3766 482205120475 4M7 5% 0,1W
3767 482205120475 4M7 5% 0,1W
3768 482211710833 10k 1% 0,1W
3769 482211683933 15k 1% 0,1W
3770 482211711139 1k5 1% 0,1W
3771 482205120122 1k2 5% 0,1W
3772 482211711507 6k8 1% 0,1W
3773 482210012227 4k7 30% 0,1W
3774 482211711383 12k 1% 0,1W
3775 482205120478 4R7 5% 0,1W
3776 482211711507 6k8 1% 0,1W
3777 482211710353 150R 1% 0,1W
3778 482205210688
!
6R8 5% 0,33W
3779 482205120334 330k 5% 0,1W
3780 482205120105 1M 5% 0,1W
3781 482205120475 4M7 5% 0,1W
3782 482211683933 15k 1% 0,1W
3783 482205120472 4k7 5% 0,1W
3784 482205120472 4k7 5% 0,1W
3785 532210011539 100k 30% 0,1W
3786 482205120223 22k 5% 0,1W
3787 482205120105 1M 5% 0,1W
3788 482205120105 1M 5% 0,1W
3789 482211710834 47k 1% 0,1W
4601 482205120008 0R Jumper 0805
4602 482205120008 0R Jumper 0805
4603 482205120008 0R Jumper 0805
4604 482205120008 0R Jumper 0805
4605 482205120008 0R Jumper 0805
4606 482205120008 0R Jumper 0805
4607 482205120008 0R Jumper 0805
4608 482205120008 0R Jumper 0805
4610 482205120008 0R Jumper 0805
4696 482205120008 0R Jumper 0805
4697 482205120008 0R Jumper 0805
4701 482205120008 0R Jumper 0805
4702 482205120008 0R Jumper 0805
4703 482205120008 0R Jumper 0805
4704 482205120008 0R Jumper 0805
4705 482205120008 0R Jumper 0805
4706 482205120008 0R Jumper 0805
4707 482205120008 0R Jumper 0805
4708 482205120008 0R Jumper 0805
4709 482205120008 0R Jumper 0805
4710 482205120008 0R Jumper 0805
4711 482205120008 0R Jumper 0805
4712 482205120008 0R Jumper 0805
4713 482205120008 0R Jumper 0805
4714 482205120008 0R Jumper 0805
4715 482205120008 0R Jumper 0805
4716 482205120008 0R Jumper 0805
4717 482205120008 0R Jumper 0805
4718 482205120008 0R Jumper 0805
4719 482205120008 0R Jumper 0805
4720 482205120008 0R Jumper 0805
4721 482205120008 0R Jumper 0805
4722 482205120008 0R Jumper 0805
4723 482205120008 0R Jumper 0805
4724 482205120008 0R Jumper 0805
4725 482205120008 0R Jumper 0805
4726 482205120008 0R Jumper 0805
4727 482205120008 0R Jumper 0805
4728 482205120008 0R Jumper 0805
4729 482205120008 0R Jumper 0805
4730 482205120008 0R Jumper 0805
4731 482205120008 0R Jumper 0805
4732 482205120008 0R Jumper 0805
4733 482205120008 0R Jumper 0805
4734 482205120008 0R Jumper 0805
4735 482205120008 0R Jumper 0805
4736 482205120008 0R Jumper 0805
4737 482205120008 0R Jumper 0805
4738 482205120008 0R Jumper 0805
4739 482205120008 0R Jumper 0805
4740 482205120008 0R Jumper 0805
4741 482205120008 0R Jumper 0805
4742 482205120008 0R Jumper 0805
4743 482205120008 0R Jumper 0805
4783 482205120008 0R Jumper 0805
4786 482205120008 0R Jumper 0805
4787 482205120008 0R Jumper 0805
4788 482205120008 0R Jumper 0805
COILS & FILTERS
5631 482215711865 Filter MPX 20kHz
5632 482215711865 Filter MPX 20kHz
5701 482215711477 Coil 2,2µH 5%
5702 482215711477 Coil 2,2µH 5%
5703 482215620946 Osc. Coil 100kHz
DIODES
6611 482213031878 1N4003G
6612 482213031878 1N4003G
6613 482213032245 BYV10-40
6614 482213030621 1N4148
6770 482213030621 1N4148
6771 482213030621 1N4148
6772 482213030621 1N4148
6773 482213030621 1N4148
6774 482213030621 1N4148
6775 482213030621 1N4148
6776 482213030621 1N4148
6777 482213034382 BZX79-C8V2
6778 482213030621 1N4148
6782 482213030621 1N4148
6785 482213030621 1N4148
6786 482213030621 1N4148
TRANSISTORS & INTEGRATED CIRCUITS
7610 532220911306 HEF4094BT
7612 532213060845 BC807-25
7613 532213060845 BC807-25
7614 532213060845 BC807-25
7616 482213060373 BC857B
7618 482213060511 BC847B
7619 482213060511 BC847B
7620 482213060511 BC847B
7622 482213060511 BC847B
7623 482213060511 BC847B
7624 482213060511 BC847B
7630 482220917322 CXA1551M
7631 482213060511 BC847B
7632 482213060511 BC847B
7633 482213060511 BC847B
7634 482213060511 BC847B
7635 482213060511 BC847B
7636 482213060511 BC847B
7637 482213060511 BC847B
7638 482213060511 BC847B
7640 482220983357 NJM4560M
7710 482220932919 HEF4952BT
7720 932214000668 AN7323S
7730 482220932919 HEF4952BT
7740 482220932919 HEF4952BT
7780 482213060511 BC847B
7781 482213042804 BC817-25
7782 482213044568 BC557B
7783 482213060511 BC847B
7784 482213060373 BC857B
7785 482213063494 J111
7786 482213063494 J111
7787 482213060511 BC847B
7788 482213060511 BC847B
7789 482213060511 BC847B
7790 482213060511 BC847B
7791 482213060511 BC847B
7792 482213060511 BC847B
Note : Only the parts mentioned in this list are normal
service spare parts.
ELECTRICAL PARTS LIST - ETF7 DOLBY BOARD
