Philips FW C717 - MECHANICAL & ACCESSORIES PARTS LIST - MAIN UNIT

13-2 13-2
M
ECHANICAL & ACCESSORIES PARTS LIST - MAIN UNIT SCREW LISTS - MAIN UNIT
185 D3 x 10
186 D3 x 12
211 D3 x 12
212 D3 x 12
213 D3 x 12
214 M3 x 12
215 M3 x 12
226 M3 x 6
227 M3 x 6
231 M3 x 6
232 M3 x 6
276 M3 x 6
277 M3 x 10
278 D3 x 12
279 D3 x 12
280 D3 x 12
283 D3 x 12
285 D3 x 12
286 D3 x 12
287 D3 x 12
292 M3 x 12
293 M3 x 12
294 M3 x 6
295 D3 x 12
296 D3 x 12
297 D2 x 8
298 D3 x 10
299 D3 x 10
300 D3 x 12
301 D3 x 12
302 D3 x 12
304 D3 x 12
305 D2 x 8
306 D3 x 12
0
101 3139 118 16980 Cabinet Front /22
0
101 3139 118 16990 Cabinet Front /34
0
103 3139 118 14320 Window CDC
0
105 3139 118 16820 Button Set CDC Select
0
106 3139 118 14340 Cover Tray CDC
0
107 4822 454 13408Badge Philips
0
111 3139 118 14350 Button Standby/Eco Power
0
115 3139 118 14370 Cover Ring Volume/VU Chrome
0
116 3140 117 64900 Window Display
0
117 3139 118 16840 Knob Volume Rotary
0
120 3139 114 72360 Frame Button Set Source Select
0
121 3139 118 14390 Button Cap Source-CD
0
122 3139 118 14400 Button Cap Source-Tuner
0
123 3139 118 14410 Button Cap Source-Tape
0
124 3139 118 14420 Button Cap Source-Aux
0
125 3139 114 72410 Lightguide Source-CD
0
126 3139 114 72420 Lightguide Source-Tuner
0
127 3139 114 72430 Lightguide Source-Tape
0
128 3139 114 72440 Lightguide Source-Aux
0
129 3139 118 14720 Button Set RDS/NEW
S /22
0
130 3139 118 14440 Button Prog/Time-Disp
0
131 3139 118 16850 Cover Ring Func Co
ntrol
0
132 3139 118 15460 Button Set Func
Control
0
133 3139 118 14470 Cap Function Control /22
0
134 3139 118 14820 Cover Ring DSC/VAC/IS
0
135 3139 118 16830 Button DSC/VAC/IS
0
140 3139 118 14500
Knob Jog Rotary
0
141 3139 118 14780 Button WOOX Plus
0
142 3139 114 72470 Frame Button Set WOOX
0
144 3140 117 64950 Button Plus WOOX Level
0
148 3139 118 17000 Cover Orn Control /22
0
148 3139 118 17010 Cover Orn Control /34
0
149 3139 118 16790 Cover Control WOOX
0
151 3139 118 16800 Cover Cassette Left
0
152 3139 118 16810 Cover Cassette Right
0
153 3139 114 74910 Lens Cassette Left
0
154 3139 114 74920 Lens Cassette Right
0
197 3139 114 68630 Door Cassette Right
0
198 3139 114 68620 Door Cassette Left
0
199 4822 402 10621 Push-Catch
0
200 4822 529 10322 Damper Assembly
0
201 3139 114 68640 Push Catch Left
0
203 4822 492 11344 S
p
rin
g
Com
p
ression
0204 4822 402 11246 Bracket Right
0205 4822 402 11245 Bracket Left
0206 3139 111 01380 Spring Torsion Right
0207 3139 111 01390 Spring Torsion Left
0209 4822 492 42787 Spring Cassette
0246 4822 462 40683 Foot Rubber (SQ)
0251 3139 114 72750 Bracket CDC Left
0252 3139 114 72760 Bracket CDC Right
0253 3139 114 73570 Panel Left
0254 3139 114 73580 Panel Right
0255 3139 114 73590 Cover Top
0256 3139 114 72790 Panel Rear /22
0271 3139 114 71010 Stopper Heatsink
0350 3140 118 51360 L/R Loudspeaker Box
0351 4822 303 50063 FM Aerial
0356 3139 118 78260 Remote Control
0384 2422 549 45067 AM Frame Aerial
0385 2422 070 98151
!
Mains Cord
0387 3140 115 29980 Instruction For Use /22
0387 3140 115 29990 Instruction For Use /34
1202 3139 110 35350 FFC Foil 11P/220/11P AD
1204 3139 110 34600 FFC Foil 07P/280/07P AD
1401 3139 110 34970 FFC Foil 19P/180/19P AD
1402 3139 110 34610 FFC Foil 11P/180/11P AD
1403 3139 110 35130 FFC Foil 06P/180/06P AD
1404 3139 110 35280 FFC Foil 10P/120/10P AD
1405 3139 110 35000 FFC Foil 08P/120/08P AD
1406 4822 320 127
52 FFC Foil 07P/180/07P AD
1407 3139 110 34010 FFC Foil 06P/140/06P AD
1501 3139 110 35120 FFC Foil 04P/400/04P BD
1503 3139 110 34800 FFC Foil 19P/120/19P BD
1601 3139 110 35050 FFC Foil 08P/220/08P AD
1702 4822 320 12654 FFC Foil 07P/220/07P AD
5001 3103 308 30630
!
Mains Transformer
Note : Only the parts mentioned in this list are normal
service spare parts.
Panel Rear /34
0
1293139118 15320 Button Set RDS/NEW
S/DOLBY /34
0
1333139118 15350 Cap Function Control /34
0256 3139 114 73100
