PHILIPS 4000 07 DISASSEMBLY
6/7
7.11. Flow-meter
Li the ow meter out of the
casing assembly and remove
the electrical and water circuit
connections.
2. Unscrew the screw shown and
remove the electrical and water
circuit connections.
1. Unscrew the screw shown at
unthread the support boiler
7.12. Boiler
7.15. KYB interface and display
Loosen the screws slide the
card o the support and
disconnect the electrical
connections.
Loosen the screw for remove the
cover.
Loosen the screws for remove
the cover.
Remove the cover. Remove the front panel
membrane
7.13. CPU board
7.14. Programming access for SSC (Saeco Service Center)
Disconnect the electrical
connections.
1
1
3
2
4
2
