12
EN
Option 2: Connect through component video
cables
Connect a progressive scan TV through
component video cables for higher quality
video.
Route audio input through the AUX-
IN sockets
You can route audio from an external device to
this product.
Connect an audio cable to:
• the AUX IN L/R sockets on this product.
• the audio output sockets on the external
device (for example, audio player).
Pr/CrYPb/Cb
AUX OUT
Connect power
Caution
• Risk of product damage! Ensure that the power supply
voltage corresponds to the voltage printed on the back
or the underside of the unit.
• Risk of electric shock! When you unplug the AC power
cord, always pull the plug from the socket. Never pull
the cord.
• Before you connect the AC power cord, ensure that
you have completed all other connections.
1 Connect the power cable to the wall
socket.
MCD2010_93_UM_V3.2.indb 12 7/1/2013 2:39:25 PM
