Overview of the main unit
Overview of the main unit
a Disc compartment
• Hold the disc.
b
• USB socket.
c MP3 LINK
• Connect external audio device.
d
• Headphone socket.
e
• Turn on the apparatus, switch to
standby mode, or Eco Power standby
mode.
f IR sensor
• Detect signals from the remote
control. Always point the remote
control at the IR sensor.
a
b
c
d
e
f
g
hij
n
m
l
k
g SOURCE
• Select a source.
h TUNING
• Rotate a photo.
• Fast backward or forward.
i
• Start or pause play.
j
• Stop play.
• Erase a program.
k PRESET
• Skip to the previous/next track, title,
or le.
• Select a programmed radio station.
