Philips ME6 - Page 109

Alignments
EN 109LC4.31E AA 8.
Table 8-4 Option codes in detail, at bit level
Option byte & bit table for restoring the TV set to its original Factory Default settings via the NVM Editor in the SAM menu
Model number
26PF5321/10/12
32PF5321/10/12
37PF5321/10/12
42F5421/10
26PF7321/12
32PF7321/12
37PF7321/10/12
OP1 Description of feature/option to be switched ON or OFF
bit 7 (msb) OP_PHILIPS_TUNER 111
bit 6 OP_FM_RADIO 000
bit 5 OP_LNA 000
bit 4 OP_ATS // for EU 111
bit 3 OP_ACI 111
bit 2 OP_UK_PNP 000
bit 1 OP_VIRGIN_MODE 000
bit 0 (lsb) OP_CHINA 000
Total DEC Value 152 152 152
Total HEX Value 98 98 98
OP2
bit 7 (msb) OP_HDMI-2X 111
bit 6 OP_IBEX (for DVB) 000
bit 5 OP_CHANNEL_NAMING 111
bit 4 OP_LTI (Lum Transcient Improvmt) 000
bit 3 OP_TILT 000
bit 2 OP_FINE_TUNING 111
bit 1 OP_BACKLIGHT_DIMMING (for Malibu only) 111
bit 0 (lsb) OP_HUE 111
Total DEC Value 167 167 167
Total HEX Value A7 A7 A7
OP3
bit 7 (msb) OP_EW_FUNCTION 000
bit 6 OP_PIXEL_PLUS (for Option A) 001
bit 5 OP_SCL_RECOVERY 111
bit 4 OP_SPLITTER // temp 000
bit 3 OP_VIRTUAL_DOLBY 111
bit 2 OP_WIDE_SCREEN 111
bit 1 OP_WSSB 111
bit 0 (lsb) OP_OP_ME5 // OP_ME5 - 5/6 local buttons implementation 1 1 1
Total DEC Value 47 47 111
Total HEX Value 2F 2F 6F
OP4
bit 7 (msb) OP_LIP_SYNC (for PDP only) 000
bit 6 OP_HD 111
bit 5 OP_1000P_TEXT 011
bit 4 OP_DELTA_VOLUME 111
bit 3 OP_TAIWAN_KOREA 000
bit 2 OP_VOLUME_LIMITER 000
bit 1 OP_STEREO_DBX 000
bit 0 (lsb) OP_STEREO_NICAM_2CS 111
Total DEC Value 81 113 113
Total HEX Value 51 71 71
OP5
bit 7 (msb) OP_AV1 111
bit 6 OP_AV2 111
bit 5 OP_AV3 111
bit 4 OP_CVI 111
bit 3 OP_SVHS2
111
bit 2 OP_SVHS3 111
bit 1 OP_HOTEL_MODE 000
bit 0 (lsb) OP_SIMPLY_FACTORY=OP_BTSC_AVSTEREO 0 0 0
Total DEC Value 252 252 252
Total HEX Value FC FC FC
OP6
bit 7 (msb) OP_PERSONAL_ZAPPING 000
bit 6 OP_SMART_SURF 000
bit 5 OP_FMTRAP 000
bit 4 OP_COMBFILTER 111
bit 3 OP_ACTIVE_CONTROL 111
bit 2 OP_VIDEO_TEXT 000
bit 1 OP_LIGHT_SENSOR 111
bit 0 (lsb) OP_TWIN_TEXT 111
Total DEC Value 27 27 27
Total HEX Value 1B 1B 1B
OP7
bit 7 (msb) OP_TIME_WIN1 000
bit 6 OP_DVB_USB = OP_MALAY 000
bit 5 OP_AMBILIGHT 000
bit 4 OP_COLUMBUS 111
bit 3 OP_DUMMY6 000
bit 2 OP_DUMMY7 000
bit 1 OP_WEST_EU 111
bit 0 (lsb) OP_MULTI_STANDARD_EUR 111
Total DEC Value 19 19 19
Total HEX Value 13 13 13
