12-4 12-4
ELECTRICAL PARTS LIST - POWER AMPLIFIER BOARD
MISCELLANEOUS
BR1 9965 000 10084 BRIDGE RECT MB252 25A 200V
F1 9965 000 10107
!
FUSE T12A 250V
F2 9965 000 10107
!
FUSE T12A 250V
RL1 9965 000 10105 RELAY MAINATURE 12VDC/5A 2P1T
RL2 9965 000 10105 RELAY MAINATURE 12VDC/5A 2P1T
RL3 9965 000 10106 RELAY MAINATURE 12VDC/12A 2P1T
SP1 9965 000 10109 SPEAKER TERMINAL 6P
SP2 9965 000 10108 SPEAKER TERMINAL 4P
CAPACITORS
C1 9965 000 10088 CAP CER KT 470PF 100V 10% SL
C2 9965 000 10086 CAP CER KT 180PF 50V 10% SL
C3 9965 000 10061 CAP ELEC EX 2,2UF 50V 20%
C4 9965 000 10089 CAP ELEC GR 100UF 50V 20%
C5 9965 000 10089 CAP ELEC GR 100UF 50V 20%
C6 9965 000 10061 CAP ELEC EX 2,2UF 50V 20%
C7 9965 000 09666 CAP CER 0,1UF 100V 20% Y5V
C8 9965 000 10091 CAP ELEC RX 220UF 35V 20%
C9 9965 000 10088 CAP CER KT 470PF 100V 10% SL
C10 9965 000 10086 CAP CER KT 180PF 50V 10% SL
C11 9965 000 10061 CAP ELEC EX 2,2UF 50V 20%
C12 9965 000 10089 CAP ELEC GR 100UF 50V 20%
C13 9965 000 10089 CAP ELEC GR 100UF 50V 20%
C14 9965 000 10061 CAP ELEC EX 2,2UF 50V 20%
C15 9965 000 09666 CAP CER 0,1UF 100V 20% Y5V
C16 9965 000 10085 CAP CER KT 100PF 100V 10% SL
C17 9965 000 10088 CAP CER KT 470PF 100V 10% SL
C18 9965 000 10086 CAP CER KT 180PF 50V 10% SL
C19 9965 000 10085 CAP CER KT 100PF 100V 10% SL
C20 9965 000 10089 CAP ELEC GR 100UF 50V 20%
C21 9965 000 10089 CAP ELEC GR 100UF 50V 20%
C22 9965 000 10085 CAP CER KT 100PF 100V 10% SL
C23 9965 000 09666 CAP CER 0,1UF 100V 20% Y5V
C24 9965 000 10091 CAP ELEC RX 220UF 35V 20%
C25 9965 000 10088 CAP CER KT 470PF 100V 10% SL
C26 9965 000 10086 CAP CER KT 180PF 50V 10% SL
C27 9965 000 10090 CAP ELEC KM 220UF 50V 20%
C28 9965 000 10089 CAP ELEC GR 100UF 50V 20%
C29 9965 000 10089 CAP ELEC GR 100UF 50V 20%
C30 9965 000 10092 CAP ELEC SG 4700UF 50V 20%
C31 9965 000 09666 CAP CER 0,1UF 100V 20% Y5V
C32 9965 000 10092 CAP ELEC SG 4700UF 50V 20%
C33 9965 000 10088 CAP CER KT 470PF 100V 10% SL
C34 9965 000 10086 CAP CER KT 180PF 50V 10% SL
C35 9965 000 10061 CAP ELEC EX 2,2UF 50V 20%
C36 9965 000 10089 CAP ELEC GR 100UF 50V 20%
C37 9965 000 10089 CAP ELEC GR 100UF 50V 20%
C38 9965 000 10093 CAP ELEC GS 47UF 50V 20%
C39 9965 000 09666 CAP CER 0,1UF 100V 20% Y5V
C40 9965 000 10085 CAP CER KT 100PF 100V 10% SL
C41 9965 000 10087 CAP CER KK 0,022UF 50V 10% Z5U
C42 9965 000 10060 CAP ELEC GR 22UF 16V 20%
C43 9965 000 10093 CAP ELEC GS 47UF 50V 20%
C44 9965 000 10089 CAP ELEC GR 100UF 50V 20%
C45 9965 000 10087 CAP CER KK 0,022UF 50V 10% Z5U
C46 9965 000 10088 CAP CER KT 470PF 100V 10% SL
C47 9965 000 10091 CAP ELEC RX 220UF 35V 20%
C48 9965 000 10091 CAP ELEC RX 220UF 35V 20%
C49 9965 000 10088 CAP CER KT 470PF 100V 10% SL
C50 9965 000 10091 CAP ELEC RX 220UF 35V 20%
C51 9965 000 10091 CAP ELEC RX 220UF 35V 20%
C52 9965 000 10089 CAP ELEC GR 100UF 50V 20%
C53 9965 000 10092 CAP ELEC SG 4700UF 50V 20%
C54 9965 000 10089 CAP ELEC GR 100UF 50V 20%
C55 9965 000 10089 CAP ELEC GR 100UF 50V 20%
C56 9965 000 10089 CAP ELEC GR 100UF 50V 20%
C57 9965 000 10092 CAP ELEC SG 4700UF 50V 20%
C58 9965 000 10085 CAP CER KT 100PF 100V 10% SL
C59 9965 000 10085 CAP CER KT 100PF 100V 10% SL
C60 9965 000 10085 CAP CER KT 100PF 100V 10% SL
C61 9965 000 10085 CAP CER KT 100PF 100V 10% SL
C62 9965 000 10085 CAP CER KT 100PF 100V 10% SL
C63 9965 000 10085 CAP CER KT 100PF 100V 10% SL
C64 9965 000 09652 CAP CER 0,1UF 50V +80/-20% Y5V
C65 9965 000 09652 CAP CER 0,1UF 50V +80/-20% Y5V
C66 9965 000 09652 CAP CER 0,1UF 50V +80/-20% Y5V
C67 9965 000 09652 CAP CER 0,1UF 50V +80/-20% Y5V
C68 9965 000 09652 CAP CER 0,1UF 50V +80/-20% Y5V
R1 9965 000 10098 RES CF 56K OHM 5% 1/6W AXIAL
R2 9965 000 09673 RES CF 1K OHM 5% 1/6W AXIAL
R3 9965 000 10094 RES CF 10 OHM 5% 1/2W AXIAL
R4 9965 000 10101 RES CF 68K OHM 5% 1/6W AXIAL
R5 9965 000 09673 RES CF 1K OHM 5% 1/6W AXIAL
R6 9965 000 10099 RES CF 5,6 OHM 5% 1/2W AXIAL
R8 9965 000 10098 RES CF 56K OHM 5% 1/6W AXIAL
R10 9965 000 10098 RES CF 56K OHM 5% 1/6W AXIAL
R11 9965 000 09673 RES CF 1K OHM 5% 1/6W AXIAL
R12 9965 000 10101 RES CF 68K OHM 5% 1/6W AXIAL
R13 9965 000 09673 RES CF 1K OHM 5% 1/6W AXIAL
R14 9965 000 10094 RES CF 10 OHM 5% 1/2W AXIAL
R15 9965 000 10099 RES CF 5,6 OHM 5% 1/2W AXIAL
R16 9965 000 10100 RES CF 6,2K OHM 5% 1/6W AXIAL
R17 9965 000 10098 RES CF 56K OHM 5% 1/6W AXIAL
R18 9965 000 10100 RES CF 6,2K OHM 5% 1/6W AXIAL
R19 9965 000 10098 RES CF 56K OHM 5% 1/6W AXIAL
R20 9965 000 09673 RES CF 1K OHM 5% 1/6W AXIAL
R21 9965 000 10101 RES CF 68K OHM 5% 1/6W AXIAL
R22 9965 000 09673 RES CF 1K OHM 5% 1/6W AXIAL
R23 9965 000 10094 RES CF 10 OHM 5% 1/2W AXIAL
R24 9965 000 10099 RES CF 5,6 OHM 5% 1/2W AXIAL
R25 9965 000 10100 RES CF 6,2K OHM 5% 1/6W AXIAL
R26 9965 000 10098 RES CF 56K OHM 5% 1/6W AXIAL
R28 9965 000 10098 RES CF 56K OHM 5% 1/6W AXIAL
R29 9965 000 09673 RES CF 1K OHM 5% 1/6W AXIAL
R30 9965 000 10101 RES CF 68K OHM 5% 1/6W AXIAL
R31 9965 000 09673 RES CF 1K OHM 5% 1/6W AXIAL
R32 9965 000 10094 RES CF 10 OHM 5% 1/2W AXIAL
R33 9965 000 10099 RES CF 5,6 OHM 5% 1/2W AXIAL
R34 9965 000 10100 RES CF 6,2K OHM 5% 1/6W AXIAL
R37 9965 000 10098 RES CF 56K OHM 5% 1/6W AXIAL
R38 9965 000 09673 RES CF 1K OHM 5% 1/6W AXIAL
R39 9965 000 10101 RES CF 68K OHM 5% 1/6W AXIAL
R40 9965 000 09673 RES CF 1K OHM 5% 1/6W AXIAL
R41 9965 000 10094 RES CF 10 OHM 5% 1/2W AXIAL
R42 9965 000 10099 RES CF 5,6 OHM 5% 1/2W AXIAL
R43 9965 000 10100 RES CF 6,2K OHM 5% 1/6W AXIAL
R44 9965 000 10098 RES CF 56K OHM 5% 1/6W AXIAL
R45 9965 000 10098 RES CF 56K OHM 5% 1/6W AXIAL
R46 9965 000 10096 RES CF 22K OHM 5% 1/6W AXIAL
R47 9965 000 10098 RES CF 56K OHM 5% 1/6W AXIAL
R48 9965 000 10097 RES CF 27K OHM 5% 1/6W AXIAL
R50 9965 000 09674 RES CF 10K OHM 5% 1/6W AXIAL
R51 9965 000 10096 RES CF 22K OHM 5% 1/6W AXIAL
R52 9965 000 10096 RES CF 22K OHM 5% 1/6W AXIAL
R53 9965 000 10096 RES CF 22K OHM 5% 1/6W AXIAL
R54 9965 000 10095 RES CF 18K OHM 5% 1/6W AXIAL
R55 9965 000 09674 RES CF 10K OHM 5% 1/6W AXIAL
COILS & FILTERS
L1 9965 000 10102 AIR COIL 2,2UH 10%
L2 9965 000 10102 AIR COIL 2,2UH 10%
L3 9965 000 10102 AIR COIL 2,2UH 10%
L4 9965 000 10102 AIR COIL 2,2UH 10%
L5 9965 000 10102 AIR COIL 2,2UH 10%
DIODES
D1 4822 130 30621 1N4148
D2 4822 130 30621 1N4148
D3 4822 130 30621 1N4148
D5 4822 130 30621 1N4148
TRANSISTORS & INTEGRATED CIRCUITS
Q2 4822 130 63082 9015C
Q3 4822 130 60644 9014C
U1 9965 000 10103 IC LM3886T AUDIO AMP
U2 9965 000 10103 IC LM3886T AUDIO AMP
U3 9965 000 10103 IC LM3886T AUDIO AMP
U4 9965 000 10103 IC LM3886T AUDIO AMP
U5 9965 000 10103 IC LM3886T AUDIO AMP
U6 9965 000 10104 IC UPC1237 SPEAKER PROTECTION
NOTE: ONLY THE PARTS MENTIONED IN THIS LIST ARE NORMAL
SERVICE SPARE PARTS.
ELECTRICAL PARTS LIST - POWER AMPLIFIER BOARD
