Technical Specifications, Connections, and Chassis Overview
EN 4 LGE PDP1.
1.1.4 Chassis Overview
Figure 1-8 PWB location
CONTROL B/D
Y-DRIVE
BOTTOM
Y-SUS
F_15590_040.eps
170605
B/D
Y-DRIVE
TOP
X-LEFT B/
D
X-RIGHT B/D
Z-SUS B/D
PSUVOLTAGE
IPM
TCP
