Mechanical Instructions
EN 6 LGE PDP4.
4. Mechanical Instructions
4.1 Mechanical Overview PDP42V7*
Figure 4-1 Cable dressing
Figure 4-2 Label location
F_15590_060.eps
200605
F_15590_000.eps
010705
F_15590_110.eps
070705
CTRL B/D
Y-SUS
Y-DRV TOP
Y-DRV BTM
X-L B/D
X-R B/D
Serial No. Position an
Information
- Board P/No.
-
Board Name
-
Serial No. of Assembl
y
Information of module
