Alignments
EN 43TPM10.1E LA 6.
2014-Jul-18
back to
div.table
This group setting of colour temperature will be applied
automatically to the TV / VGA / HDMI / AV sources.
Note: The information of the RGB value is only for reference,
the specific value is based on model adjustment.
6.4 Option Settings
6.4.1 Introduction
The microprocessor communicates with a large number of I
2
C
ICs in the set. To ensure good communication and to make
digital diagnosis possible, the microprocessor has to know
which ICs to address. The presence / absence of these
MT5580 ICs is made known by the option codes.
Notes:
• After changing the option(s), save them by pressing the OK
button on the RC before the cursor is moved to the left,
select STORE and press OK on the RC.
• The new option setting is only active after the TV is
switched “off” / “stand-by” and “on” again with the mains
switch (the NVM is then read again).
6.4.2 Option Code Overview
Enter SAM mode to check the option codes. they could be
edited in the NVM.
6.4.3 Display Code Overview
Press the following key sequence on a standard RC
transmitter: “062598” directly followed by MENU and “xxx”,
where “xxx” is a 3 digit decimal value of the panel type: see
column “Display Code” in back to div.table 6-3
. After resetting
the Display Code, restart the set immediately.
Table 6-3 Display code overview
Normal (9000K) 50PFL4208T/12 128 110 105
50PFL5008T/60 128 111 110
Cool (11000K) 32PFL3078K/12 112 95 124
32PFL3008T/60 108 97 128
32PFL3208H/12 112 93 127
32PFL4208K/12 116 95 124
32PFL4208T/12 128 108 128
32PFL4208T/12 125 96 123
32PFL4308H/12 125 128 127
32PFL4508H/12 125 120 128
32PFL5008H/12 120 125 118
39PFL3208T/12 126 103 128
39PFL4208K/12 126 112 128
40PFL3078T/12 126 112 127
40PFL4308H/12 127 112 128
40PFL4418H/12 128 105 125
40PFL4508H/12 128 103 124
42PFL3008T/12 112 93 123
42PFL3208H/12 87 117 128
42PFL4208K/12 128 105 128
42PFL5008H/12 120 101 128
46PFL3008T/60 121 108 128
46PFL3108H/12 128 106 112
46PFL3208H/12 128 101 108
46PFL4208H/12 128 105 110
46PFL4308H/12 128 116 127
46PFL4418H/12 128 97 103
46PFL4508H/12 128 116 127
46PFL4908H/12 126 120 123
47PFL5008H/12 128 97 103
50PFL4208T/12 128 115 125
50PFL5008T/60 128 114 128
Warm (6500K) 32PFL3078K/12 123 96 77
32PFL3008T/60 128 109 94
32PFL3208H/12 128 96 77
32PFL4208K/12 123 89 125
32PFL4208T/12 128 91 69
32PFL4208T/12 127 115 115
32PFL4308H/12 128 96 77
32PFL4508H/12 128 96 115
32PFL5008H/12 128 96 77
39PFL3208T/12 128 94 79
39PFL4208K/12 128 94 72
40PFL3078T/12 128 100 80
40PFL4308H/12 128 108 79
40PFL4418H/12 128 90 75
40PFL4508H/12 128 81 62
42PFL3008T/12 127 90 120
42PFL3208H/12 123 128 96
42PFL4208K/12 128 90 80
42PFL5008H/12 128 89 77
46PFL3008T/60 127 115 115
46PFL3108H/12 127 115 120
46PFL3208H/12 127 115 120
46PFL4208H/12 128 110 70
46PFL4308H/12 128 93 62
46PFL4418H/12 128 80 47
46PFL4508H/12 128 93 62
46PFL4908H/12 125 96 70
47PFL5008H/12 128 80 47
50PFL4208T/12 128 90 75
50PFL5008T/60 128 96 68
Picture mode Screen size
Colour temperature
Red Green Blue
CTN_ALT BOM# Panel Type Display Code
32PFL3008T/60 TPT315B5-TU4A 196
32PFL3018T/60 TPT315B5-TU4A 196
32PFL3078K/12 TPT315B5-DXJSFE 233
32PFL3078T/12 TPT315B5-DXJSFE 233
32PFL3118K/12 TPT315B5-DXJSFE 233
32PFL3118T/12 TPT315B5-DXJSFE 233
32PFL3158K/12 TPT315B5-HVN01 S200D 169
32PFL3158K12 TPT315B5-EUJFFA 221
32PFL3158K/12 TPT315B5-HVN01 S210C 226
32PFL3208H/12 TPT315B5-TU4A 196
32PFL3208H/12 TPT315B5-DXJSFE 220
32PFL3208K/12 TPT315B5-TU4A 196
32PFL3208K/12 TPT315B5-DXJSFE 220
32PFL3208T/12 TPT315B5-TU4A 196
32PFL3208T/12 TPT315B5-DXJSFE 220
32PFL3258H/12 TPT315B5-HVN01 169
32PFL3258H/12 TPT315B5-EUJFFA 221
32PFL3258K/12 TPT315B5-HVN01 169
32PFL3258K/12 TPT315B5-EUJFFA 221
32PFL3258T/12 TPT315B5-HVN01 169
32PFL3258T/12 TPT315B5-EUJFFA 221
32PFL3258T/60 TPT315B5-HVN01 169
32PFL3258T/60 TPT315B5-EUJFFA 221
32PFL4208H/12 TPT315B5-DXJSFE 215
32PFL4208K/12 TPT420H2-HVN04 168
32PFL4208K/12 TPT315B5-DXJSFE 215
32PFL4208M/08 TPT315B5-DXJSFE 215
32PFL4208T/12 TPT315B5-TU4A 184
32PFL4208T/12 TPT315B5-DXJSFE 215
32PFL4208T/60 TPT315B5-DXJSFE 215
32PFL4218H/12 TPT315B5-DXJSFE 215
32PFL4218K/12 TPT315B5-TU4A 184
32PFL4218T/12 TPT315B5-TU4A 184
32PFL4218T/60 TPT315B5-TU4A 184
