14
Eingänge
1: 10 ... 30 V DC
2: GND_1
3: GND_2
4: Hold
Ausgänge
5: 0 ... 24 mA (Iout)
6: GND_3
7: 0 ... 12 V DC (Uout)
6. Anschlussbelegung
Blockschaltbild und Anschluss siehe
Punkt 1.4
Schraubanschluss RM5.08:
0,14 ... 1,5 mm
2
, 26 ... 16 AWG
7. Lieferumfang
1 Digitalanzeige
1 Spannbügel
1 Frontrahmen für
Spannbügelbefestigung,
für Einbauquerschnitt 50 x 25 mm
1 Frontrahmen für Schraubbefestigung,
für Einbauquerschnitt 50 x 25 mm
1 Dichtung
1 Bedienungsanleitung multilingual
10. Abmessungen siehe Klappseite
8. Bestellbezeichnung
Sollwertgeber
MCR-SL-D-SPA-UI
Artikelnummer: 2710314
9. Fehlermeldungen
Err0: Programmierfehler, z. B.: der
eingegebene Wert ist höher als ou.Hi
Phoenix Contact GmbH & Co.KG
Postfach 1341
D-32819 Blomberg
Telefon: (05235) 3-00
Telefax: (05235) 3-4 12 00
www.phoenixcontact.com
