Phoenix Contact MCR-SL-D-SPA-UI User Manual

12
Technical Data (Continued)
Protection: IP 65 front
Weight: approximately 50 g
Inputs: 2 front side keys for setting and programming
Hold input, optocoupler, high active
low: 0 .. 2 VDC / high: 4 .. 30 VDC
Outputs: Current output 0 ... 24 mA, increment 10 μA
Load 20 mA up to < 500 Ohms, > 20 mA up to < 400 Ohms
Ripple: <10 mVss
Voltage output 0 ..12 V, increment 10 mV,
Load > 2 kOhms, Ripple: <10 mVss
Accuracy: < 0,2 % of the final value +
0,02 %/K
Inputs
1: 10 ... 30 V DC
2: GND_1
3: GND_2
4: Hold
Outputs
5: 0 ... 24 mA (Iout)
6: GND_3
7: 0 ... 12 V DC (Uout)
6. Connecting Diagram
Block diagram and connection see
point 1.4
Screw terminals RM5.08:
0,14 ... 1,5 mm
2
, 26 ... 16 AWG
7. Scope of Delivery
1 Digital display
1 Panel mounting clip
1 Bezel for clip mounting,
panel cut-out 50 x 25 mm
1 Bezel for screw mounting,
panel cut-out 50 x 25 mm
1 Gasket
1 Multilingual operating manual
10. Dimensions, see folding pages
9. Error Messages
Err0: Programming error, e.g.: the
value input is above ou.Hi
8. Order Information
Setpoint generator
MCR-SL-D-SPA-UI
2710314
Phoenix Contact GmbH & Co.KG
Postfach 1341
D-32819 Blomberg
Tel: 0049 5235 3-00
Fax: 0049 5235 3-4 12 00
www.phoenixcontact.com
