Starting up the printer
106986_en_01 PHOENIX CONTACT 11
2.4 Inserting the material cartridge
Figure 2-3 Replacing the material cartridge
• Keeping the material cartridge straight, insert it into the compartment from
above so that it engages with a click.
Make sure that the material end is in the output tray.
• To remove the material cartridge, pull it upward while keeping it straight.
2.5 Switching on the device
• Switch on the printer using the green key.
• Press the green key until the display lights up.
NOTE: Damage to the printer and material cartridge
If the printer is not going to be used for a prolonged period of time, remove the
material cartridge from the printer.
ON/OFF
ON/OFF
