TacFusion User Manual A1
Table 2. Feature and function.
No
Feature
Function
1
Eyeshades
Adjustable diopter range.
2
Eyepieces
Viewing the screen.
3
Day/Night Vision Lens
Letting the visible light in.
4
Thermal Lens
Letting the infrared light in.
5
Battery Compartment
Powering the device by the batteries.
6
Proximity Sensor
Detecting human eyes that are approaching in order to save power.
The OLED screen turns on automatically when eyes are detected.
1.5.2 Cables Description
The aviation plug cable can be connected to connector, which is located at the bottom part of TacFusion.
Figure 3. Cable description
Table 3. Cable description
No
Feature
Function
1
BNC
Connect it to the display.
2
USB
Connect it to your PC to back up videos/images.
3
DB9
Reserved.
