5.3 Attaching the Snap-on Ferrite
INFORMATION
The 000015165 snap-on ferrite ensures the electromagnetic compatibility of the
hexapod system. It is intended for permanent attachment to the power supply cable
of the hexapod.
When attaching the snap-on ferrite, make sure that it is correctly positioned on
the cable. The snap-on ferrite can only be removed with special tools (not
included in the scope of delivery).
Attach the snap-on ferrite to the power supply cable of the hexapod before you
connect the hexapod to the power supply for the first time.
Tools and accessories
000015165 snap-on ferrite, included in the scope of delivery (p. 19)
Permanently attaching the snap-on ferrite
1. Put the power supply cable of the hexapod into the open snap-on ferrite
approx. 10 to 15 cm behind the D-sub 3W3 connector (m) that is intended for
connection to the power supply.
2. Close the snap-on ferrite:
a) Align the cable so that it is not squeezed when the snap-on ferrite is
closed.
b) Carefully press the two halves of the snap-on ferrite around the cable
until the lock engages.
5.4 Mounting the Hexapod on a Surface
CAUTION
Possible squeezing during mounting!
When positioning the hexapod on a surface there is a risk of minor injuries due to the
mass of the hexapod.
When you hold the hexapod by the base plate to position it on a surface: Ensure
that your hands remain in a position where they cannot be squeezed.
