10 Technical Data
62 Version: 2.1.1 MS222E H-845 Hexapod System
H845B0021
Miscellaneous
Operating voltage 24 V, max. 8 A
Operating temperature
range
5 to 40°C
Mass 2.8 kg
10.1.4 Maximum Ratings Hexapod Controller
Input on:
Maximum
Operating Voltage
Operating
Frequency
Maximum Current
Consumption
4-pin M12 panel plug (m) 24 V
8 A
10.1.5 Data Table M850B0448 Power Supply
M850B0448 Power Supply
Output voltage 24 V DC / 20 A max
Input voltage 110 – 230 V AC (50 – 60 Hz)
Input power 700 W
Output power 500 W
Fuses 2 x IEC T 8 AL (with 250 V rated voltage)
Dimensions 236 mm x 132 mm x 296 mm + handles
Mass 4.7 kg
10.1.6 Maximum Ratings M850B0448 Power Supply
The power supply is designed for the following operating data:
Maximum Operating
Voltage
Maximum Operating
Frequency (Unloaded)
Maximum Output Power
230 V AC
60 Hz 500 W
