52 Version: 2.1.1 MS222E H-845 Hexapod System
13. Place the cardboard box around the hexapod, see figure above.
Figure 23: Hexapod package without cardboard lid
14. Insert the hard foam insert for the motion platform of the hexapod in the
cardboard box, see figure above.
15. Close the cardboard box with the cardboard lid.
16. Secure the box on the pallet.
7.3 Replacing the Fuses of the M850B0448 Power Supply
NOTICE
Damage of power supply!
The M850B0448 power supply can be damaged if unsuitable fuses are used.
Check and replace both fuses if there is a fault.
