PI H-845 - Scope of Delivery

3 Product Description
H-845 Hexapod System MS222E Version: 2.1.1 19
3.4 Scope of Delivery
Hexapod
Item ID Description
Hexapod mechanics, one of the following models (according to the order):
H845B0008
H845B0014
H845B0024
H845B0034
H845B0016
H845B0035
System component of H-845.D11
System component of H-845.D21
System component of H-845.D31
System component of H-845.D41
System component of H-845.D51
System component of H-845.D61
Packaging of hexapod mechanics, consisting of:
Packaging materials:
 Pallet
 Cardboard box, lower part
 Cardboard box, upper part
 Compound foil
 Hard foam insert for motion platform of hexapod
 Hard foam insert for base plate of hexapod
Documentation, consisting of:
H845T0001 Technical note in printed form on unpacking the hexapod
MS247EK Short instructions for hexapod systems
Screw sets:
Accessories for mounting the hexapod on a surface:
 6 M12x60 screws ISO 4762
 1 Allen wrench 10.0 DIN 911
000036450 Accessories for connection to the grounding system:
 1 flat-head screw with cross recess M4x8 ISO 7045
 2 washers, form A-4.3 DIN 7090
 2 safety washers, Schnorr Ø 4 mm N0110
