Introduction to AVMTM2
3.3 Technical data
General Electric Characteristics
Supply voltage 22–28 VDC (typical 24 VDC)
Maximum ripple 1V
RMS
, 50-60 Hz
Power consumption Nom. 2.6W @ 28 VDC (max. 7.5W)
Maximum load on the outputs 40 mA (short-circuit protected)
MTBF (electronics) 40,000 hours according to MIL-HDBK-217E
Reversed polarity protection 5 minutes at 23°C [73.4°F]
Valve units
Function on/off Normally closed (NC/NC 2) or normally open (NO)
Function blow-off Normaly closed (NC)
LED status indicator, colour Red
Vacuum switches
Outputs 2 digital, 24V, S1 and S2
Vacuum signal levels See the table in the “setting of the vacuum-signal level” section.
Hysteresis Fixed 7 kPa ±1 kPa [2.1 inHg ±0.3 inHg]
Response time <10 mS
Maximum overpressure 0.7 MPa [101.5 psi]
LED status indicator, colour Green
Limit value for air saving function (ES) Level according to output S2
Other data
Blow-off capacity Adjustable 0–7.5Nl/s [0-15.9scfm]
Operating temperature 0-50°C [32-122°F]
Materials Al, PA, NBR, SS, PMMA, ABS
Degree of protection IP65 [NEMA 4]
Cable (accessory) 2 and 5 m PUR
Humidity 90% RH
