PIAB AVM 2 - Page 9

ManualAVM
TM
2Page 9/24
Safety instructions
3.4.2 Dimensions P5010
P5010
Figure 4 P5010.
1. Compressed air, 2. Vacuum, 3. Exhaust
3.4.3 Dimensions P6010
P6010
34
1.34"
82
3.23"
53
2.09"
G1/8", 1/8"NPSF
G1/8", 1/8"NPSF
G1/4", 1/4"NPSF
G1", 1"NPSF
2
3
4x M5
25 0.984"
170
6.69"
22
0.866"
214
8.42"
117
4.61"
G1"
73
2.87"
5.5 0.217"
7.5 0.295"
10.5
0.413"
G1", 1" NPSF
G1/4"
G1/4"
M12 8-pin
73 2.87"
148.4 5.84"
18.5
0.728"
M5
1
3
2
E
P
1
2
3
Figure 5 P6010.
1. Compressed air, 2. Vacuum, 3. Exhaust
