Pilot Communications SPM33 User Manual

case IP20
Project standard Test level
IEC
Electrostatic
Discharge Immunity
Test
GB/T17626.2-2006
(IEC61000-4-2:2001)
Class 4
Radiated immunity
test
GB/T17626.3-2006
(IEC61000-4-3:2002)
Class 4
Electrical fast
transient/burst
immunity test
GB/T17626.4-2008
(IEC61000-4-4:2006)
Class 4
Surge immunity test GB/T17626.5-2008
(IEC61000-4-5:2005)
Class 4
RF field immunity
induced mass
GB/T17626.6-2008
(IEC61000-4-6:2006)
Class 3
Radiated emissions
limit
GB 9254-2008
(CISPR22：2006)
Accord
Voltage dips, short
interruptions
immunity test
GB/T17626.11-2008
(IEC61000-4-11:2004)
Accord
Power frequency
withstand voltage
GB/T 17215.211-2006 Rated insulation
voltage≤300V，The
test voltage
2000V。
Rated insulation
voltage≤60V，The
test voltage
1000V。
Leakage current
≦10mA。
26
