Pilot Communications SPM33 User Manual

7. Technical Datasheet
Parameters range
Rated
operating
parameters
Rated Power Supply AC 85~265V
DC 100~300V
Rated input current 5A or 1A
Rated input voltage 3×220/380V 35Hz~65Hz
Status input
Rated voltage
220V，2 channel active status input, less than
60V is open, more than 140V is closed，Max.
Input is 300V.
Relay output
Rated contact
capacity
AC 250V/5A or DC 30V/5A
parameter range Accuracy
Accuracy of
electric
parameters
voltage 10%~150% 0.5%
current 1%~120% 0.5%
Power factor -1~1 1%
Active energy 0~99999999.9 0.5%
Reactive energy 0~99999999.9 2%
Active power
Single phase：0 ~ ±
26MW/var/VA
Total ：0 ~ ± 78MW/var/VA
0.5%
Reactive power 1.0%
Three-phase current
unbalance
0%~100% 1%
Harmonic content 0%~100%
B 级
parameters Performance
Power Consumption ≤ 2W/5VA
Cabinet
temperature
Normal operating
temperature
-10℃～+55℃
Limit operating
temperature
-25℃～+55℃
Storage temperature
-40℃～+70℃
Relative humidity
5％～95% RH, non-condensing
Insulation
ability
Power frequency
withstand voltage
2000VAC
Insulation resistance ≥ 100MΩ
Impulse voltage 6000V
IP index front panel IP52
25

Pilot Communications SPM33 Specifications

General

Brand	Pilot Communications
Model	SPM33
Category	Measuring Instruments
Language	English
