Pilot Communications SPM33 - List of Harmonic Data Registers

8.6.3 List of harmonic data registers
Register
address
Rea
d/wr
ite
attri
bute
Definition
Data
type
Description
40801 RO Va - THD UINT16 Calculation factor:
0.001
40802
RO Vb - THD
40803 RO Vc - THD
40804 RO Ia – THD UINT16
Calculation factor:
0.001
40805 RO Ib – THD
40806 RO Ic – THD
40807 RO 2nd harmonic component of Va UINT16
Calculation factor:
0.001, Unit: %
40808 RO 3rd harmonic component of Va
55
