19
2. Install the rudder servo arm with
cable attach points aft.
Rudder Servo Assembly
The rudder cables and couplers come
factory installed as shown.
Rudder Servo (A)
1. Drill 1mm holes and mount the
rudder servo with the output shaft
facing forward.
3. Tape the rudder to the vertical
fin in the neutral position to help
with the rigging.
To Next Page
