PNOZ e3.1p

Operating Manual PNOZ e3.1p

21240-EN-09

| 28

Mechanical data 774139 784139

Conductor cross section with screw

terminals

1 core flexible 0,25 - 2,5 mm², 24 - 12 AWG –

2 core with the same cross sec-

tion, flexible with crimp connect-

ors, no plastic sleeve 0,25 - 1 mm², 24 - 16 AWG –

2 core with the same cross sec-

tion, flexible without crimp con-

nectors or with TWIN crimp con-

nectors 0,2 - 1,5 mm², 24 - 16 AWG –

Torque setting with screw terminals 0,5 Nm –

Stripping length with screw termin-

als 8 mm –

Conductor cross section with

spring-loaded terminals: Flexible

with/without crimp connector – 0,2 - 1,5 mm², 24 - 16 AWG

Spring-loaded terminals: Terminal

points per connection – 2

Stripping length with spring-loaded

terminals – 8 mm

Dimensions

Height 94 mm 101 mm

Width 22,5 mm 22,5 mm

Depth 121 mm 121 mm

Weight 130 g 130 g

Where standards are undated, the 2020-07 latest editions shall apply.
