PNOZ e3.1p
Operating Manual PNOZ e3.1p
21240-EN-09
| 30
Remove plug-in terminals
Procedure: Insert the screwdriver into the housing recess behind the terminal and lever the
terminal out.
Do not remove the terminals by pulling the cables!
Order reference
Product
Product type Features Connection type Order no.
PNOZ e3.1p 24 V DC Screw terminals 774139
PNOZ e3.1p C 24 V DC Spring-loaded terminals 784139
Accessories
Product type Features Order no.
Terminal block filter 1 Terminal block with filter for 3-10 kOhm load range 774195
Terminal block filter 2 Terminal block with filter for 10-30 kOhm load range 774196
