Commissioning
Operating Manual PNOZ m B0.1
1005720-EN-04
| 22
Input circuit Single-channel Dual-channel
Emergency stop
without detection of shorts across
contacts
S1
IM0
L+
S1
IM1
IM0
L+
L+
Emergency stop
with detection of shorts across
contacts
IM0
T0M20
S1
S1
T1M21
IM1
T0M20
IM0
Start circuit Input circuit without detection
of shorts across contacts
Input circuit with detection of
shorts across contacts
I5
S3
L+
I5
T0M20
S3
Semiconductor outputs
Redundant output
K2
L-
O0 (O2)
O1 (O3)
K1
L-
Single output
K3
L-
K4
O0 (O2)
O1 ( O3)
K1
L-
K2
