Commissioning
Operating Manual PNOZ m B0.1
1005720-EN-04
| 25
7.7 Connection example
Dual-channel E-STOP and safety gate wiring, monitored start (IM18), feedback loop (IM16)
IM0
IM1
IM2
IM3
I4
I5
I6
I7
I8
I9
I10
I11
I12
I13
I14
I15
IM16
IM17
IM18
IM19
T0M20
T1M21
T2M22
T3M23
O0
O1
O2
O3
A1
A2
24V
0V
K1
K2
S1
K2
K1
S2
S3
L+
L-
