10.1 Safety characteristic data
NOTICE
You must comply with the safety characteristic data in order to achieve the
required safety level for your plant/machine.
Unit Operating
mode
EN ISO
13849-1:
2015
PL
EN ISO
13849-1:
2015
Category
EN IEC
62061
SIL CL/
maximum
SIL
EN IEC
62061
PFH
D
[1/h]
EN/IEC
61511
SIL
EN/IEC
61511
PFD
EN ISO
13849-1:
2015
T
M
[year]
Logic
CPU 2-channel PL e Cat. 4 SIL 3 4,74E-10 SIL 3 4,00E-05 20
Expansion
left – PL e Cat. 4 SIL 3 3,30E-11 SIL 3 2,49E-06 20
Expansion
right – PL e Cat. 4 SIL 3 2,79E-11 SIL 3 2,18E-06 20
Input
Inputs 1-channel PL d Cat. 2 SIL 2 3,85E-09 SIL 2 3,38E-04 20
Inputs 2-channel PL e Cat. 4 SIL 3 7,95E-11 SIL 3 6,90E-06 20
Inputs Short cir-
cuit-form-
ing safety
mats PL d Cat. 3 SIL 2 1,06E-09 SIL 2 9,14E-05 20
Inputs 1-ch.,
pulsed
light bar-
rier PL e Cat. 4 SIL 3 3,85E-10 SIL 3 3,40E-05 20
Output
SC outputs 1-channel
with re-
duced
fault de-
tection PL d Cat. 2 SIL 2 2,45E-09 SIL 2 1,04E-04 20
SC outputs 2-channel
with re-
duced
fault de-
tection PL e Cat. 4 SIL 3 4,87E-09 SIL 3 2,06E-04 20
SC outputs 1-channel
with ad-
vanced
fault de-
tection PL e Cat. 4 SIL 3 1,66E-11 SIL 3 1,46E-06 20
SC outputs 1-channel PL d Cat. 2 SIL 2 1,57E-10 SIL 2 1,35E-05 20
