Technical details
Operating Manual PNOZ m B0.1
1005720-EN-04
| 40
Mechanical data
Material
Bottom PC
Front PC
Top PC
Connection type Spring-loaded terminal, screw terminal
Mounting type plug-in
Conductor cross section with screw terminals
1 core flexible 0,25 - 2,5 mm², 24 - 12 AWG
2 core with the same cross section, flexible without
crimp connectors or with TWIN crimp connectors 0,2 - 1,5 mm², 24 - 16 AWG
Torque setting with screw terminals 0,5 Nm
Conductor cross section with spring-loaded terminals:
Flexible with/without crimp connector 0,2 - 2,5 mm², 24 - 12 AWG
Spring-loaded terminals: Terminal points per connec-
tion 2
Stripping length with spring-loaded terminals 9 mm
Dimensions
Height 101,4 mm
Width 45 mm
Depth 120 mm
Weight 220 g
Where standards are undated, the 2022-05 latest editions shall apply.
