Technical details
Operating Manual PNOZ m B0.1
1005720-EN-04
| 39
Environmental data
Ambient temperature
in accordance with the standard EN 60068-2-14
Temperature range 0 - 60 °C
Forced convection in control cabinet off 55 °C
Storage temperature
in accordance with the standard EN 60068-2-1/-2
Temperature range -25 - 70 °C
Climatic suitability
in accordance with the standard EN 60068-2-30, EN 60068-2-78
Condensation during operation Not permitted
Max. operating height above SL 2000 m
EMC EN 61131-2
Vibration
in accordance with the standard EN 60068-2-6
Frequency 5 - 150 Hz
Acceleration 1g
Shock stress
in accordance with the standard EN 60068-2-27
Acceleration 15g
Duration 11 ms
Airgap creepage
in accordance with the standard EN 61131-2
Overvoltage category II
Pollution degree 2
Protection type
in accordance with the standard EN 60529
Housing IP20
Terminals IP20
Mounting area (e.g. control cabinet) IP54
Potential isolation
Potential isolation between SC output and system voltage
Type of potential isolation Basic insulation
Rated insulation voltage 30 V
Rated surge voltage 2500 V
Mechanical data
Mounting position horizontally on mounting rail
DIN rail
Top hat rail 35 x 15 EN/IEC 60715, 35 x 7,5 EN/IEC 60715
Recess width 27 mm
Cable length
Max. cable length per input 1 km
Sum of individual cable lengths at the test pulse
output 2 km
