Operation
Operating Manual PNOZ m B0.1
1005720-EN-04
| 28
Display Example Description
DEVICE INFO
Device information for the
base unit and expansion
modules
Page 1:
Pos: 0
PNOZ m B0.1
SW:
03.00.00
03.00
Page 2:
Pos: 0
PNOZ m B0.1
H:
0
Page 1
1st line: Module position
(Pos)
2nd line: Product type
3rd line: Firmware version
4th line: Software version
Page 2
1st line: Module position
(Pos)
2nd line: Product type
3rd line: Operating hours
SHOW OPERATING INFO
Displays specific operating
parameters of the base unit
and expansion units
Page 1:
Pos: 0
10.000ms
24.0V
25.0°C
Cycle:
Supply:
Temp:
Page 2:
Pos: 1
f1: 1.000Hz
f2: 0.000Hz
1st line: Module position
(Pos)
2nd to 4th line: Specific op-
erating parameters
e.g.:
Cycle time
Supply voltage
Operating temperature
Frequencies
SHOW ERROR STACK
Error stack display
Show
error stack?
Shows the error stack
entries
ERROR STACK
Error stack entries
1/64
PA: 00 00 00
EC: 83
00 00
EN: 01
CH: A
1st line: Sequential number
and
channel (CH)
2nd line: Error class (EC)
and error number (EN)
3rd line: Error parameter
(PA)
4th line: Continuation of er-
ror parameter (PA)
IP ADDRESS
IP address of base unit
(only appears on base units
to which a communication
module with Ethernet inter-
face is connected)
2nd line: IP Address
3rd line: Subnet mask
