Pilz PNOZ ms1p - Connection Examples

Commissioning
OperatingManualPNOZms1p
20967EN11
23
6.6 Connectionexamples
6.6.1 Connectionof2proximityswitchesandanincrementalencoder
Description
} 2proximityswitches,pnpswitching
} 1incrementalencoder
Speed monitor
DriveIncremental Encoder
PNOZ msi15p
Fig.:Connectionof2proximityswitches,pnpswitching,oneincrementalencoder
