Pilz PNOZ ms1p - Device Front View and Indicators

Overview
OperatingManualPNOZms1p
20967EN11
8
2.3 Frontview
Key:
} X1:
– I10,I11:
connectionterminalsforproximityswitchataxis1
– I20,I21:
connectionterminalsforproximityswitchataxis2
– 0V,24V:
supplyconnections
} X12:
– femaleconnectorfortheconnectionofanincrementalencoderataxis1
} X22:
– femaleconnectorfortheconnectionofanincrementalencoderataxis2
} LEDs:
– POWER
– FAULT
– SHAFT1
– SHAFT2
– X12
– X22
