Technicaldetails
OperatingManualPNOZms1p
20967EN11
28
8 Technicaldetails
General
Approvals
BG,CCC,CE,EAC(Eurasian),KOSHA,TÜV,
cULusListed
Electricaldata
Supplyvoltage
for Modulesupply
Voltage 5,0V
Kind DC
Voltagetolerance 2%/+2%
Powerconsumption 1,0W
Statusindicator LED
Proximityswitchinput
Numberofinputs 4
Inputsignallevel
Signallevelat"1" 1130V
Signallevelat"0" 35V
Inputresistance 3kOhm
Input'sfrequencyrange 03kHz
Configurablemonitoringfrequency
Withouthysteresis 0.1Hz3kHz
Withhysteresis 0.2Hz3kHz
Incrementalencoderinput
Numberofinputs 2
Connectiontype RJ45femaleconnector,8pin
Supplyvoltageforincrementalencoders 5VDC±10%,typ.30mA
Inputsignallevel 0,55,0Vss
PhasepositionforthedifferentialsignalsA,/Aand
B,/B 90°±30°
Overloadprotection 3030V
Inputresistance 10,0kOhm
Input'sfrequencyrange 0500kHz
Configurablemonitoringfrequency
Withouthysteresis 0.1Hz500kHz
Withhysteresis 0.2Hz500kHz
Times
Configurableswitchoffdelay 02.500ms
Supplyinterruptionbeforedeenergisation 20ms
Reactiontime
f>100Hz:Configurableswitchoffdelay+switch
offdelayofbaseunit 10ms
f<100Hz:Configurableswitchoffdelay+switch
offdelayofbaseunit 10ms+1/f
