PNOZ s11
Operating Manual PNOZ s11
21693-EN-11
| 12
Application examples
Single device
} Single-channel
} Driven via safety relay with safety contacts
In1
In2
Out
Fault
PNOZ s11
24VDC
1413
2423
3433
4443
6463
7473
8483
9493
5251
PNOZ s11 24VDC
PILZ.750111
A1
A2
feedback loop input
13
14
-K1
51
52
-K1
safety relay
FBL_1 FBL_2
24VDC
0V
